2024 Peterbilt 389 & Jerr-Dan HDR1000 50/60 Ton JFB Gold Body Series Rotator
- Manufacturer: Peterbilt
- Model:389
- Exterior Color: White
- Engine Manufacturer: Cummins
- Engine Type :X-15
- Fuel Type: Diesel
- Horsepower: 605
- Transmission: Eaton Fuller
- Suspension: Air
- Ratio: 4.10
- Drive Tires: 11R24.5
- Steer Tires: 425/65R22.5
- Wheelbase: 376 in
- Front Axle Weight: 20,000 lbs
- Rear Axle Weight: 52,000 lbs.
- Wrecker Brand: Jerr-Dan
- Wrecker Class: Heavy Duty
- Wrecker Body: Heavy Duty
- Wrecker Rating: 50/60-Ton Rotator
- Winch Rating: 50,000 lbs.
- Dana Spicer 20K Front Axle
- Simard 20k front steer
- Bendix Air Cam Front Drum Brakes
- Dana Spicer 52K Rear Axles
- Self-Steering 20K Pusher Axle
- 4.10 Rear Axle Ratio
- Anti-Lock Braking System
- Bendix Air Cam Rear Drum Brakes
- Dash Mounted Dump Switch w/Indicator light for rear suspension
- Cummins X15 605HP Motor
- 376 in Wheelbase
- Eaton Fuller 18spd Transmission
- 110 gal Fuel Tank LH U/C
- Peterbilt Premium Ultraride Air Ride Black Driver & Passenger Seats
- Leather Wrapped Steering Wheel
- Platinum Interior –Artic Grey
- Stainless Steel Mirrors HTD & Motorized
- (4) Round Air Horns
- Midlevel Speaker System
- CB Terminals
- AM/FM/Sirius-XM Radio
- SmartNav System
The Jerr-Dan HDR1000 50/60 Ton JFB Gold Series 274-5TS Rotator Wrecker
283 inch Cab-to-Tandem Chassis Length
Equipped with a 3 Stage High Strength Hydraulic Boom featuring:
- Wireless Fully Proportional Remote for Boom and Winches w/ cord and extra battery & charger
- Max Boom extension 41’ 5”
- Max working height 42’ 8” (Ground to Hook)
- Boom angle indicators
- 360º Continuous Boom rotation
Max Lifting Capacity:
Boom AngleRetractedExtended60º120,000 lb.35,500 lb.30º100,000 lb.20,000 lb.0º57,600 lb.17,000 lb.
Equipped with Five (5) Winches:
(2) 50,000lb. Ramsey® Hercules 2 Spd Main Winches w/ 3/4” x 250’ Cable
(1) 50,000lb. Ramsey® Hercules 2 Spd Underlift Drag Winch w/ 3/4” x 250’ Cable
(2) 20,000lb. Ramsey® AUX Winches w/ 9/16” x 135’ Cable
500LP 3-Stage Coach Underlift:
- 50,000 lbs. retracted lift capacity at 71 inches off tailboard
- 17,000 lbs. extended lift capacity at 143 inches off tailboard
- Non-Proportional Remote
S130 Outrigger w/ Low Profile Scissor-Style Outriggers
- Outriggers Footprint 112 inch long x 220 inches wide
- Upgrade – 30 inch ground penetration
- Upgrade – Includes six (6) Outrigger 24 inch square Pads
JFB Gold Storage Solution
The following describes the storage spaces available on this unit. The equipment stored in these compartments is sold separately. We offer a large selection of incident management equipment so ask your sales specialist for assistance equipping your wrecker for the road.
This JFB Rotator Includes the Following Storage:
57 inch Tunnel Box
Rotary Chain Rack
– Patent Pending Chain Carousel | Shop Chains
– Free rotation with locking mechanism
Chain Binder Storage Compartment
– 4 Designated places for standard chain binders
Tilt Down Drawers
– 3 tilt down drawers each with 180 lbs. capacity (size 36” x 43”)
Snatch Block Storage Spaces
– 8 designated adjustable size places for snatch blocks | Shop Snatch Blocks
Shackle Storage Spaces
– 24 “peg board” style hooks for shackle placement
A Sliding Chain Board
– Sliding board extends 16 inches
A C-Tech Brand Toolbox
– All aluminum construction with powder coated finish
A Storage Compartment for Recovery Tools
– Space for an axe
– Storage for a sledge hammer Up to 12 lb.
– Space for 36 inch bolt cutters
Storage Shelves for Miscellaneous Tools
– Aluminum shelves for variety of tools, rigging etc. | Shop Rigging & Lifting Equipment
– Fully adjustable, can be removed from body
Dedicated Storage Spaces for the following type of equipment (equipment sold separately):
– Traffic Cones accommodates 12 – 36” DOT approved cones
– Ladder
– Tow Light | Shop Tow Lights
– Wheel Chocks | Shop Wheel Chocks
– Bottle Jack
– Flashlight | Shop Flash Lights
– Fire Extinguisher | Shop Fire Extinguishers
– Shovel
– Grizzly Bar
– Spreader Bar | Shop Spreader Bars
Frame Fork Storage
– Adjustable Polypropylene shelving for 7 sets of Frame Forks
PEDESTRAIN Bridge Fabrication Bid Estimate Vehicle
NAOMI JEANETTE ROBINSON LOGISTICS GROUP
1444 Jefferys Road #580
Rocky Mount, NC 27804
Office: (252)877-2108
Fax (252)877-2117
Cell (252)903-3751
Toll Free (844)415-3410
Freight Forwarding & Fabrication
U.S. Highway-17 @ N.C. Highway-32 - Edenton, NC
ACRE PERCENTAGE
Truck Garage Shop
([4] Bays 20' Wide x 100' Length)
0.19% of a Acre
Fabrication Shop
(Rotators Bay, Carriers Bay, Wreckers Bay & Servicing Bay)
(12' Wide x 120' Length)
0.14% of a Acre
Brokering & Forwarding Office
(100' Wide x 100' Length)
0.23% of a Acre
Nearest Highways (Within 20 Miles)-
- U.S. Route -17
- U.S. Route - 64
- U.S. Route - 13
- N.C. Route - 45
Nearest Interstates (Within 68 Miles)-
- Interstate-95
- Interstate-64
- Interstate-664
Peterbilt 589 TWIN STEER Tri-Axle w/nrc-85CSR Rotator
N.J.R. GROUP PIPE LAYING & HEAVY DUTY RECOVERY
NAOMI JEANETTE ROBINSON LOGISTICS GROUP
1444 Jeffreys Road
Rocky Mount, NC 27804
Toll Free Phone# (844)415-3410
Office# (252)877-2108
Cell# (252)903-3751
Fax# (252)877-2117
Toll Free# (844)415-3410
https://www.njrtruckingllc.com
Business Infographics
Towing Division -
2025 PETERBILT 589 TRI-AXLE - TWIN STEER 356” WHEELBASE w/NRC 85-TON ROTATOR
- TOTAL SPECIFICATIONS (Driver’s and Passenger’s Side)
- Total Length…………….477” (39.75’)
- Wheelbase………………380” (31.6’)
- Gross Vehicle Weight Rating……67,500 lbs.
- Tare Weight (Estimated & Max Weight Preferred)...61,000 lbs.
- 23,000 lbs Front Steer Axle Center Hub Location (Front to Rear)......31” (2.5’)
- 23,000 lbs. Twin Steer Axle Center Hub Location (Front to Rear).....160” (13.3’)
- Peterbilt 589 Stainless Steel 100 - Gallon Fuel Tank with Steps (Front to Rear).....81” to 129”
- Zips In The Ditch SP50000 Sidepuller, (2) 25,000 lbs. Winches Boom 50,000 lbs. Capacity Intergrated (Front to Rear):.........132” to 138”
- Vulcan Omnipro 220Industrial Multiprocess Welder with 120/240V Input - Enclosure
- Fortress 5-Gallon 225 psi High Performance Wheeled Jobsite Air Compressor - Enclosure
- Predator 3500 Watt Super Quiet Inverter Generator w/CO Secure Technology - Enclosure
- Titanium 65-Amp Plasma Cutter Cuts 1 3/16” Thick Metal - Enclousre
- (2) Heavy Duty Spreader Bars
- Front Outrigger (Front to Rear).........203” to 221”
- 23,000 lbs. Lift Steerable Axle Hub Location (Front to Rear)........299”
- 23,000 lbs. Front Drive Axle Hub Location (Front to Rear).......353”
- 23,000 lbs. Rear Drive Axle Hub Location (Front to rear) …….407”
- Rear Outrigger (Front to Rear)......434” to 452’
- Boom in Travel Position (Front to Rear)......477”
- Peterbilt 46,000 lbs. Tandem Drive Axle Hub Location (Front to Rear).......355” & 409”
NRC 85-TON ROTATOR LIFTING CAPABILITIES LIMITATIONS
Stage #1 - 30’ Max. Height / Stage #2 - 43’ Max. Height / Stage #3 - 53’ Max Height
LIFTING CAPABILITY
BOOM STAGE
Angle
BOOM HEIGHT
MAX. WEIGHT RECOVERY HEIGHT
MIN. WEIGHT RECOVERY HEIGHT
EQUIPMENT
# OF ROTATORS REQUIRED
LIFTING CAPABILITY - 79.2 to 26.5 Tons
BOOM STAGE - 158,400 lbs. To 53,000 lbs.
Angle - 70 Degrees
BOOM HEIGHT - 53’ Max
MAX. WEIGHT RECOVERY HEIGHT - 30’
MIN. WEIGHT RECOVERY HEIGHT - 53’
EQUIPMENT - Cat 374 Excavator
# OF ROTATORS REQUIRED - (Stage #1 Boom 30’) Recovery Lift 1’ Distance or more Need 2-Rotators
LIFTING CAPABILITY - 77.2 to 18.2 Tons
BOOM STAGE - 154,400 lbs. To 36,400 lbs.
Angle - 60 Degrees
BOOM HEIGHT - 50’ Max
MAX. WEIGHT RECOVERY HEIGHT - 27’
MIN. WEIGHT RECOVERY HEIGHT - 50’
EQUIPMENT - Cat D9 Dozer
# OF ROTATORS REQUIRED - (Stage #1 Boom 27’) Recovery Lift 2’ Distance or more Need 2-Rotators
LIFTING CAPABILITY - 59.4 to 14.1 Tons
BOOM STAGE - 118,800 lbs. To 28,200 lbs.
Angle - 50 Degrees
BOOM HEIGHT - 45’ Max
MAX. WEIGHT RECOVERY HEIGHT - 25’
MIN. WEIGHT RECOVERY HEIGHT - 45’
EQUIPMENT - Cat 988K Loader
# OF ROTATORS REQUIRED - (Stage #1 Boom 25’) Recovery Lift 5’ Distance or more Need 2-Rotators
LIFTING CAPABILITY -41 to 11.8 Tons
BOOM STAGE - 82,000 lbs. To 23,600 lbs.
Angle - 40 Degrees
BOOM HEIGHT - 39’ Max
MAX. WEIGHT RECOVERY HEIGHT - 23’
MIN. WEIGHT RECOVERY HEIGHT - 39’
EQUIPMENT - Cat MH3022 Wheel Material Handlers
# OF ROTATORS REQUIRED - (Stage #1 Boom 23’) Recovery Lift 8’ Distance or more Need 2-Rotators
LIFTING CAPABILITY - 33.3 to 10.5 Tons
BOOM STAGE - 66,600 lbs. To 21,000 lbs.
Angle - 30 Degrees
BOOM HEIGHT - 33’ Max
MAX. WEIGHT RECOVERY HEIGHT - 19’
MIN. WEIGHT RECOVERY HEIGHT - 33’
EQUIPMENT - Cat 973K Track Loader
# OF ROTATORS REQUIRED - (Stage #1 Boom 19’) Recovery Lift 10’ Distance or more Need 2-Rotators
LIFTING CAPABILITY - 29.3 to 9.7 Tons
BOOM STAGE - 58,600 lbs. To 19,400 lbs.
Angle - 20 Degrees
BOOM HEIGHT - 25’ Max
MAX. WEIGHT RECOVERY HEIGHT - 16’
MIN. WEIGHT RECOVERY HEIGHT - 25’
EQUIPMENT - Volvo EC220E Excavator
# OF ROTATORS REQUIRED - (Stage #1 Boom 16’) Recovery Lift 11’ Distance or more Need 2-Rotators
LIFTING CAPABILITY - 27.2 to 9.2 Tons
BOOM STAGE - 54,400 lbs. To 18,400 lbs
Angle - 10 Degrees
BOOM HEIGHT - 17’ Max
MAX. WEIGHT RECOVERY HEIGHT - 13’
MIN. WEIGHT RECOVERY HEIGHT - 17’
EQUIPMENT - Volvo L120H Wheel Loader
# OF ROTATORS REQUIRED - (Stage #1 Boom 13’) Recovery Lift 12’ Distance or more Need 2-Rotators
LIFTING CAPABILITY - 26.6 to 9.1 Tons
BOOM STAGE - 53,200 lbs. To 18,200 lbs.
Angle - 0 Degrees
BOOM HEIGHT - 9’ Max
MAX. WEIGHT RECOVERY HEIGHT - 9’
MIN. WEIGHT RECOVERY HEIGHT - 9’
EQUIPMENT - Volvo ABG PTR240 Asphalt Compactor
# OF ROTATORS REQUIRED - (Stage #1 Boom 8’) Recovery Lift 13’ Distance or more Need 2-Rotators
Dependable Towing & Repair Quotes
NAOMI JEANETTE ROBINSON LOGISTICS GROUP
1444 Jefferys Road #580
Rocky Mount, NC 27804
Office: (252)877-2108
Fax (252)877-2117
Cell (252)903-3751
Toll Free (844)415-3410
C 85-TON ROTATOR BOOM RECOVERY PULLING CAPABILITIES LIMITATIONS
Stage #1 - 30’ Max. Height / 0 - 70 Degrees
THERE ARE 4 TYPES OF RE
NRSISTANCE ENCOUNTERED IN OUR INDUSTRY
- ROLLING RESISTANCE
- GRADIENT RESISTANCE
- 15% OF GRADIENT: The force of gravity moving up or down a grade45% OF GRADE: The force of gravity moving up or down a grade
- DAMAGE RESISTANCE
- DAMAGE: Is the force that resist the movement when rolling object is damaged
- 30% OF GRADIENT: The force of gravity moving up or down a grade
- ROLLING HARD: Hard Flat Ground and the load on the wheels on concrete and tires are inflated
- ROLLING SOFT: It is on soft surface such as grass or gravel
- GRADIENT RESISTANCE
- MIRE RESISTANCE
- TIRE MIRE: When tire is sunk into the dirt, gravel, mud, sand or other soft surface
- WHEEL MIRE: If it is sunk up to lower part of the wheel Rim
- BODY MIRE: If it is sunk up to the body
NRC 85-TON ROTATOR SIDE RECOVERY w/(2) 25,000 lbs. WINCHES PULLING CAPABILITIES LIMITATIONS
One Line Recovery - 16,778.5 lbs.
One Line with Snatch Block - 33,557.0 lbs.
Two Line Recovery - 33,557.0 lbs.
Two Line Recovery with Two Snatch Blocks - 67,114.0 lbs.
THERE ARE 4 TYPES OF RESISTANCE ENCOUNTERED IN OUR INDUSTRY
- ROLLING RESISTANCE
- ROLLING HARD: Hard Flat Ground and the load on the wheels on concrete and tires are inflated
- ROLLING SOFT: It is on soft surface such as grass or gravel
- MIRE RESISTANCE
- TIRE MIRE: When tire is sunk into the dirt, gravel, mud, sand or other soft surface
- WHEEL MIRE: If it is sunk up to lower part of the wheel Rim
- BODY MIRE: If it is sunk up to the body
- GRADIENT RESISTANCE
- 15% OF GRADIENT: The force of gravity moving up or down a grade
- 30% OF GRADIENT: The force of gravity moving up or down a grade
- 45% OF GRADE: The force of gravity moving up or down a grade
- DAMAGE RESISTANCE
- DAMAGE: Is the force that resist the movement when rolling object is damaged
