WELCOME TO OUR GRADING, PAVING & GROUNDS DIVISION
NAOMI JEANETTE ROBINSON LOGISTICS GROUP
1444 Jeffreys Road
Rocky Mount, NC 27804
Toll Free Phone# (844)415-3410
Office# (252)877-2108
Cell# (252)903-3751
Fax# (252)877-2117
Toll Free# (844)415-3410
https://www.njrtruckingllc.com
N.J.R. Group Grading segment presentation illustration through sub-contractor entrance, to generate growth and expand our dominion in the industry.
Grading and landscaping segment presentation illustration through company vehicles of choice.
All Equipment in Grading, Landscaping & Recycling is Under Contract.
Naomi Jeanette Robinson Group was giving a livelihood through Frank Criscola (Crisdel Group). A well-known microentrepreneur out of South Plainfield, NJ.
I was familiarized with Construction in 1998 by Mr. Albano Graco (Portuguese Grade Phenom). A legend in grading, concrete, pipe laying and demolition.
I was enlightened about being a Grade Foremen by Mr. Ray Walhour and Mr. Guy Centennial to be a professional Grade Foremen in 1996.
Mr. James Robinson (Father) and Mr. Calvin Robinson (Cousin) has indoctrinated me on operating heavy equipment for grading and paving through Local 825 Operating Engineer (I.U.O.E.)
Mr. Joe Logan (Business Agent / Local 825), adopted me through the union to teach me about the duties of a Lead Engineer on a job site and how to work with fellow brothers’ and sisters’ in the union.
Naomi Jeanette Robinson Group mission is to evacuate doubt with achievable. Our goal is to be moderate in this industry. To survey my dreams and ambitiousness and excavate into authenticity.
As we grow into the industry our management and vision will expand to a new perception.
Naomi Jeanette Robinson Group is a limited liability corporation and is owned solely by Tariq Robinson.
Naomi Jeanette Robinson Group is a sole proprietorship company which will be owned and operated by Mr. Tariq Robinson.
The business has journeying contracts with reliable clients. These major companies, that are affiliate with Naomi Jeanette Robinson Group gaining of prosperity are located throughout
- North Carolina
- South Carolina
- Georgia
- Virginia
- Tennessee
- Maryland
- Delaware
- Pennsylvania
The bargain agreement accordingly to the delegated states. We will look to make our prevailing remuneration from custom homes builders, such as America's Home Place, Toll Brothers and Mid-Atlantic.
Naomi Jeanette Robinson Group was introduced into the Grading and Landscaping by Lowe's Pro Service.
However, our objective is to broaden our horizon in the Surveying and Engineering industry.
NAOMI JEANETTE ROBINSON LOGISTICS GROUP
1444 Jefferys Road #580
Rocky Mount, NC 27804
Office: (252)877-2108
Fax (252)877-2117
Cell (252)903-3751
Toll Free (844)415-3410
FORD TRANSIT 350 HD DRONE SURVEYING DIVSION VEHICLE WITH BALL HITCH REAR BUMPER & ATC 24' TRAILER
2026 Ford Transit 350 HD Extended
Chassis Information
- Engine - 3.5L Ecoboost V6
- Transmission - 10-Speed Automatic
- Drive - All Wheel Drive
- 148" Wheelbase
- Base Curb Weight - 5,838 lbs.
- Gross Combination Weight Rating - 13,000 lbs.
- Gross Vehicle Weight Rating - 11,000 lbs.
- Max. Payload - 5,103 lbs.
- Seating Capacity - 2 Seats
- High Capacity Trailer Tow Package
- Exterior Backup Alarm
- Backup Camera
Van Interior Information - TNT Upfitters
- Walk Through Bulkhead with 36" LCD Mointer with Rear HDMI Cord Capabilties from Rear door or Side Door
- Bosch GRL4000-80CHVK Revolve Dual Grade Rotar Laser Charging Port for Several Batteries
- Dewalt Charging Tools Port for Several Batteries
- Craftsman Tools Chest and Tools
- Slide Out Tabe Tray in Middle at Rear with Dewalt 12" Miter Saw Attachment with Charging USB-C Charging Ports and Power Outlet
- Kobalt Drill Press Compartment
- Dewalt Router Saw Table Kit Compartment
- Air Compressor with Lines Below Rear Door
- Trailer Hitch Ball with Electric Brakes Connection
ATC STO 450 - 8.5' x 24' w/Lifetrac Enclosed Trailer
- Caterpillar CUV105-D UTV with zXT UR HD Heavy Duty Tracks
- Lifetrac Office with Desk and Printer Station
- Backup Camera
KENWORTH T380 w/STELLAR TMAX-2 GRADING, LANDSCAPING & MASONARY DIVISION FOREMEN VEHICLE WITH GLOBE 2
.webp/:/cr=t:0%25,l:0%25,w:100%25,h:100%25/rs=w:600,cg:true)
CHASSIS SPECS:
2026 Kenworth T380 Trans: Allision 3500RDS 6-Speed w/ PTO Drive Gear HP: 330
- GVWR: 33,000 lbs.
- Front Axle: 12,000 lbs.
- Rear Axle: 21,000 lbs.
- Wheelbase: 192"
- CA: 124" Tires: 11R22.5
Stellar TMAX2-14 Aluminum Mechanics Body:
- 14' Aluminum Body,
- Side Packs and Doors All Compartments Raised to 60"
- Isolated Steel Crane Compartment with Torsion box understructure
- Master-Lock system Exterior
- LED DOT light package
- Stellar 12630 Telescopic Crane: 12,000 lbs.
- Max Capacity (77,800 ft*lbs.) 30' Full Hydraulic Reach CDT Pro Proportional Radio Remote Control Rear Stabilizer - Hydraulic Out / Down - Up To 84,000 ft-lbs. Crane Boom Tip Light - Gravity Rotating -
- Dual LED Trilliant Lights for Bar Style Flip Sheave
- Stellar 46P Hydraulic Air Compressor: CFM / PSI: 46 CFM @ 175 PSI 22 Gallon Air Tank FLR System - (1) Outlet for Air Hose 1/2" x 50' Hose Reel w/ Roller Guide
FORD F550 CREW CAB w/16' HYDRAULIC DUMP TRAILER FOR ASPHALT & CONCRETE RECYLING & PAVING DIVISION
FORD F550 CREW CAB w/16' HYDRAULIC DUMP TRAILER FOR ASPHALT & CONCRETE RECYLING & PAVING DIVISION
FORD F550 CREW CAB w/16' HYDRAULIC DUMP TRAILER FOR ASPHALT & CONCRETE RECYLING & PAVING DIVISION
2026 Ford F550 King Cab Mechanics Truck
Chassis Information
- 192" Wheelbase
- 84" CA Supercab
- 6.7L V8 Powerstroke
- XLT Trim
- 10 Speed Auto Transmission w/ PTO
- Rapid Cab Supplemental Heater
- Engine Block Heater
- 19,500# GVWR Package
- High Capacity Trailer Tow Package
- Extra Heavy Duty Front End Suspension
- Exterior Backup Alarm
- Backup Camera
Stellar TMAX 30k Aluminum Mechanics Body (Specifications):
- 11' Aluminum Body,
- Applicable Chassis:14,000 – 22,900 GVWR
Clear Cab to Axle:60" (152 cm) or 84" (213 cm)
Body Length:109" (277 cm) or 133" (338 cm)
Compartment Depth:22" (56 cm)
Floor Width:50" (127 cm)
Body Width:94" (239 cm)
Body Height:• 44" (112 cm)
•52" (132 cm) with or without an 8" (20 cm) drop well for 60" bottle storage
Net Weight:2,038 – 3,105 lbs (925 – 1,409 kg)
BUMPER PULL DUMP TRAILER
Manufacturer: Iron Bull
Model: Dump Trailer
Year: 2026
Floor Length: 16ft
Floor Width: 7in
Gvwr: 14,000 lbs
Payload Capacity: 14,000 lbs
Color: Black
Pull Type: Bumper
Axles: 2
Construction: Steel
GRADING, LANDSCAPING RECYCLING EQUIPMENT DIVISION TRACTOR
FORD F550 CREW CAB w/16' HYDRAULIC DUMP TRAILER FOR ASPHALT & CONCRETE RECYLING & PAVING DIVISION
FORD F550 CREW CAB w/16' HYDRAULIC DUMP TRAILER FOR ASPHALT & CONCRETE RECYLING & PAVING DIVISION
2026 KENWORTH W-900B TRI AXLE w/86" STUDIO SLEEPER
- Wheelbase - 315"
- Tare Weight - 25,350 lbs.
- Cummins X15 Power Plant with 605hp Producing 2050Torq
- Transmission - 18 Speed Manual
- Aux. 4 Speed Transmission - Spicer TTC AP01750-4C air shift
- Pusher Axle - 22.5K Non-steer
- Fixed Lower Bunk
- Suspension - 52K Neway
TRAVELING AXLE TRAILER
2026 Landoll 950E Traveling Tail Tri Axle Trailer
- Kingpin to Center Axle Spacing -37'7"
- Net Weight - 21,780 lbs.
- Deck Traveling Height - 37.5"
TRUCK & TRAILER WEIGHT RATING
- Kenworth & Landoll Empty Weight - 47,130 lbs.
- Shipment Legal Dimension on Trailer - Width 8.5' - Length 53' - Height 124" - Weight 32.870 lbs.
GLOBE 80-TON LOWBOY, GLOBE 55-TON LOWBOY & EXTREME TRAILERS STEP DECK TRI AXLE TRAILERS FOR EQUIPMENT TRANSPORT
KENWORTH W900B & GLOBE 80- TON LOWBOY
NORTH CAROLINA DEPARTMENT OF TRANSPORTATION (NCDOT) LIMITATIONS:
- Tare Weight Per Axles - 6,192 lbs.
- Heavy Weight Per Axle - 20,000 lbs.
- Tare Weight Per Axles Group - 16,100 lbs.
- Heavy Weight Between Axle Group - 59,500 lbs.
- Weight Allowed On Top of a Axle Group When Loading - 30,250 lbs.
- Shipment Contact Patch Over Axle Group - 9'L x 8.5'W
FEDERAL BRIDGE RATING
- Tractor % of Total Weight - 25% (65,000 lbs. or Slide 5th Wheel to the rear)
- Jeep % of Total Weight - 25% (65,000 lbs. or Adjust the 5th Wheel on Jeep to the Forward Position)
- Lowboy % of Total Weight - 25% (65,000 lbs. or Adjust Shims on Booster
- Booster % of Total Weight - 20% (52,000 lbs. Max. Weight or Adjust Shims
KENWORTH W900B & GLOBE 55- TON LOWBOY
NORTH CAROLINA DEPARTMENT OF TRANSPORTATION (NCDOT) LIMITATIONS:
- Tare Weight Per Axles - 6,724 lbs.
- Heavy Weight Per Axle - 18,500 lbs.
- Tare Weight Per Axles Group - 16,943 lbs.
- Heavy Weight Between Axle Group - 59,000 lbs.
- Weight Allowed On Top Deck of Lowboy - 29,050 lbs.
- Shipment Contact Patch Over Lowboy Quad Axle - 14'6"'L x 8.5'W
FEDERAL BRIDGE RATING
- Tractor % of Total Weight - 55% (82,786 lbs. or Slide 5th Wheel to the rear)
- Lowboy % of Total Weight - 44% (65,604 lbs. or Load the Shipment 11' From Center of Drive and Trailer axles to put more weight on trailer and off tractor
KENWORTH W900B & EXTREME TRAILERS XS70 STEP DECK
NORTH CAROLINA DEPARTMENT OF TRANSPORTATION (NCDOT) LIMITATIONS:
- Tare Weight Per Axles - 6,225 lbs.
- Heavy Weight Per Axle - 20,000 lbs.
- Tare Weight Per Axles Group - 12,450 lbs.
- Heavy Weight Between Axle Group - 55,000 lbs.
- Weight Allowed On Top Deck of Step Deck - 22,140 lbs.
- Shipment Contact Patch Over Step Deck Tridem Axle Patch Over Axles - 9'L x 8.5'W
FEDERAL BRIDGE RATING
- Tractor % of Total Weight - 74% (104,784 lbs. or Slide 5th Wheel to the rear. Must Put Shipment Close to Trailer First Axle to Offset the Tractor Weight of being Overweight)
- Step Deck % of Total Weight - 25% (35,182.56 lbs. When Over 80,000 lbs. Gross Load from 1st Trailer Axle and out
GLOBE GTBN803-67-28-HGG 80-TON 3+3+3 MODULAR EAST COAST SETUP
GLOBE 85-TON DECK TYPES
- Beam -34'L x 4'W x 24"H
- Drop Side - 34'L x 8.5'W x 18"H
- Flat Deck - 34'L x 9'W x 24"H
KENWORTH W900B & GLOBE 85-TON WEIGHT AND MEASURE
KENWORTH W900B TARE WEIGHT - 25,350 lbs.
GLOBE 85-TON TARE WEIGHT - 55,000 lbs.
KENWORTH W900B TRACTOR
- Front Bumper to Steer Axle - 30" (2.5')
- Steer Axle to Lift Axle - 234" (19.5')
- Lift Axle to Front Drive Axle - 54" (4.5')
- Front Drive to Rear Drive Axles - 54" (4.5')
- Rear Drive to 1st Jeep Axle - 169" (14')
GLOBE TRIDEM JEEP
- 1st Jeep Axle to 2nd Jeep Axle - 60" (5')
- 2nd Jeep Axle to 3rd Jeep Axle - 60" (5')
- 3rd Jeep Axle to 1st Lowboy Axle - 542" (45.1')
GLOBE 85- TON LOWBOY
- 1st Lowboy Axle to 2nd Lowboy Axle - 60" (5')
- 2nd Lowboy Axle to 3rd Lowboy Axle - 60" (5')
- 3rd Lowboy Axle to 1st Booster Axle - 112" (9.3')
GLOBE TRIDEM AXLE BOOSTER
- 1st Booster Axle to 2nd Booster Axle - 60" (5')
- 2nd Booster Axle to 3rd Booster Axle - 60" (5')
- 3rd Booster Axle to Rear of Booster - 36" (3')
KENWORTH W900B & GLOBE 85-TON DIMENSIONS
- Total Length - 1,591" (132')
- # of Articulate Sections - 4
- Avg. Feet Per Section - 397.75" (33')
- Min. Intersection Space Required to Make a Turn - 4 Lane Road (50' x 50' Intersection)
- Complete Tractor & Trailer Tare Weight - 80,350 lbs.
TRANSPORTING DEADHEAD & DELIVERY JOBSITE AND SOIL REQUIREMENTS
PSI RATING:
- # of Tires - 48
- # of Axles - 13
- # of Axles Group - 5
- Avg. Spacing Between Axles Group - 26.5' Spacing Between Axles Group
- Kenworth W900B Tractor Tare Weight - 25,350 lbs.
- Globe 3+3+3 Setup 80-Ton Lowboy Tare Weight - 55,000 lbs.
- Gross Combination Tare Weight - 80,350 lbs.
- Tare Weight PSI Rating: 557 lbs. PSI
SAFETY WEIGHT PERMITS
DEADHEAD EXPENSES EXPLAIN
- Contact Patch - 12" x 12"
- Tare Weight PSI Rating: 557 lbs. PSI
- Tare Weight Per Tire Average - 1,673 lbs. Average Weight Per Tire
- Steer Axle Rating - 20,000 lbs.
- Lift Axle Rating - 22,000 lbs.
- Drive Axles Rating - 46,000 lbs.
- Jeep Axles Rating - 75,000 lbs.
- Lowboy Axles Rating - 75,000 lbs.
- Booster Axles Rating - 75,000 lbs.
- Total Rating - 313,000 lbs
NCDOT RATING
- Steer Axle Axle Tire Width & Rating - 20" (10,000 lbs.) at 20,000 lbs
- Lift Axle - 22" (10,000 lbs.) at 20,000 lbs.
- Drives & Trailer - 12.5" (6,250 lbs.)
AXLES GROUP & NCDOT RATING
- Steer - 20,000 lbs.
- Drives Tridems - 60,000 lbs.
- Jeep Tridem - 60,000 lbs.
- Lowboy Tridem - 60,000 lbs.
- Booster Tridem - 60,000 lbs.
- Total NCDOT Weight Allowed Empty or Heavy - 260,000 lbs.
- Axles Permit - 20,000 lbs.
- All Tires Must Be - 10" Min. Width (on duals) 20" Singles
GLOBE GTBN553-53-26-HGG 55-TON QUAD AXLE (4th Axle Flip) MODULAR EAST COAST SETUP
GLOBE 55-TON DECK TYPES
- Beam -33'L x 4'W x 22"H
- Drop Side - 33'L x 8.5'W x 14"H
- Flat Deck - 33'L x 8.5'W x 22"H
KENWORTH W900B & GLOBE 55-TON WEIGHT AND MEASURE
KENWORTH W900B TARE WEIGHT - 25,350 lbs.
GLOBE 55-TON TARE WEIGHT - 25,480 lbs.
KENWORTH W900B TRACTOR
- Front Bumper to Steer Axle - 30" (2.5')
- Steer Axle to Lift Axle - 234" (19.5')
- Lift Axle to Front Drive Axle - 54" (4.5')
- Front Drive to Rear Drive Axles - 54" (4.5')
- Rear Drive to 1st Quad Axle - 537" (44.75')
GLOBE 55-TON QUAD AXLE LOWBOY
- 1st Quad Axle to 2nd Quad Axle - 54" (4.5')
- 2nd Quad Axle to 3rd Quad Axle - 54" (4.5')
- 3rd Quad Axle to 4th Quad Axle - 84" (7')
- 4th Quad Axle to Rear of Trailer - 36" (3)
KENWORTH W900B & GLOBE 55-TON DIMENSIONS
- Total Length - 1,137" (94.75')
- # of Articulate Sections - 2
- Avg. Feet Per Section - 568.5" (47.375')
- Min. Intersection Space Required to Make a Turn - 71.0625' - 6 Lane Road (72' x 72' Intersection)
- Complete Tractor & Trailer Tare Weight - 50,830 lbs.
TRANSPORTING DEADHEAD & DELIVERY JOBSITE AND SOIL REQUIREMENTS
PSI RATING:
- # of Tires - 28
- # of Axles - 8
- # of Axles Group - 3
- Avg. Spacing Between Axles Group - (379") 31.5' Spacing Between Axles Group
- Kenworth W900B Tractor Tare Weight - 25,350 lbs.
- Globe 55-Ton Quad Axle Lowboy Tare Weight - 25,480 lbs.
- Gross Combination Tare Weight - 50,830 lbs.
- Tare Weight PSI Rating: 352 lbs. PSI
SAFETY WEIGHT PERMITS
EXPENSES EXPLAIN
- Contact Patch - 12" x 12"
- Tare Weight PSI Rating: 352 lbs. PSI
- Tare Weight Per Tire Average - 1,681 lbs. Average Weight Per Tire
- Steer Axle Rating - 20,000 lbs.
- Lift Axle Rating - 22,000 lbs.
- Drive Axles Rating - 46,000 lbs.
- Quad Axles Rating - 100,000 lbs.
- Total Rating - 188,000 lbs.
NCDOT RATING
- Steer Axle Axle Tire Width & Rating - 20" (10,000 lbs.) at 20,000 lbs.
- Lift Axle - 22" (10,000 lbs.) at 20,000 lbs.
- Drives & Trailer - 12.5" (6,250 lbs.)
AXLES GROUP & NCDOT RATING
- Steer - 20,000 lbs.
- Drives Tridems - 60,000 lbs.
- Trailer Quads - 68,000 lbs.
- Total NCDOT Weight Allowed Empty or Heavy - 148,000 lbs.
- Axles Permit - 18,500 lbs.
- All Tires Must Be - 10" Min. Width (on duals) 20" Singles
EXTREME TRAILERS XS70 TRIDEM STEP DECK ON 22.5" RIMS
EXTREME TRAILERS XS70 DECK SPEC
- Top -11'L x 8.5'W x 51"H
- Bottom - 42'L x 8.5'W x 40"H
KENWORTH W900B & EXTREME TRAILER XS70 WEIGHT AND MEASURE
KENWORTH W900B TARE WEIGHT - 25,350 lbs.
EXTREME TRAILERS XS70 TARE WEIGHT - 12,000 lbs.
KENWORTH W900B TRACTOR
- Front Bumper to Steer Axle - 30" (2.5')
- Steer Axle to Lift Axle - 234" (19.5')
- Lift Axle to Front Drive Axle - 54" (4.5')
- Front Drive to Rear Drive Axles - 54" (4.5')
- Rear Drive to 1st Step Deck Axle - 327.75" (27.31')
EXTREME TRAILER XS70 STEP DECK
- 1st Trailer Axle to 2nd Trailer Axle - 54" (4.5')
- 2nd Trailer Axle to 3rd Trailer Axle - 54" (4.5')
- 3rd Trailer Axle to End of Trailer - 138" (11.5')
KENWORTH W900B & EXTREME TRAILERS XS70 STEP DECK DIMENSIONS
- Total Length - 945.75" (78.81')
- # of Articulate Sections - 2
- Avg. Feet Per Section - 472.875" (39.40')
- Min. Intersection Space Required to Make a Turn - 709.31" (59.10') - 4 Lane Road w/Center Turn Lane (60' x 60' Intersection)
- Complete Tractor & Trailer Tare Weight - 37,350 lbs.
TRANSPORTING DEADHEAD & DELIVERY JOBSITE AND SOIL REQUIREMENTS
PSI RATING:
- # of Tires - 24
- # of Axles - 7
- # of Axles Group - 3
- Avg. Spacing Between Axles Group - (315.25") 26.27' Spacing Between Axles Group
- Kenworth W900B Tractor Tare Weight - 25,350 lbs.
- Extreme Trailer XS70 Step Deck Tare Weight - 12,000 lbs.
- Gross Combination Tare Weight - 37,350 lbs.
- Tare Weight PSI Rating: 259 lbs. PSI
SAFETY WEIGHT PERMITS
EXPENSES EXPLAIN
- Contact Patch - 12" x 12"
- Tare Weight PSI Rating: 259 lbs. PSI
- Tare Weight Per Tire Average - 1,556.25 lbs. Average Weight Per Tire
- Steer Axle Rating - 20,000 lbs.
- Lift Axle Rating - 22,000 lbs.
- Drive Axles Rating - 46,000 lbs.
- Tridem Axles Rating - 75,000 lbs.
- Total Rating - 163,000 lbs.
NCDOT RATING
- Steer Axle Axle Tire Width & Rating - 20" (10,000 lbs.) at 20,000 lbs.
- Lift Axle - 22" (10,000 lbs.) at 20,000 lbs.
- Drives & Trailer - 12.5" (6,250 lbs.)
AXLES GROUP & NCDOT RATING
- Steer - 20,000 lbs.
- Drives Tridems - 60,000 lbs.
- Trailer Tridem - 60,000 lbs.
- Total NCDOT Weight Allowed Empty or Heavy - 140,000 lbs.
- Axles Permit - 20,000 lbs.
- All Tires Must Be - 10" Min. Width (on duals) 20" Singles
PRESUMPTIVE VALUES OF ALLOWABLE BEARING PRESSURE FOR SPREAD FOUNDATIONS
Type of Bearing Soil - Rock, Granite, Diorite
Consistency in Place - Hard, Sound Rock
Allowable Bearing Pressure (Tons Per Square Feet)
- Range: 60 to 100 Tons
- Recommended Value For Use - 80 Tons
Type of Bearing Soil - Slate
Consistency in Place - Medium Hard, Sound Rock
Allowable Bearing Pressure (Tons Per Square Feet)
- Range: 30 to 40 Tons
- Recommended Value For Use: 35 Tons
Type of Bearing Soil - Hard Cemented Shales, Siltstone, Sandstones, Limestones with Cavities
Consistency in Place - Hard, Sound Rock
Allowable Bearing Pressure (Tons Per Square Feet) -
- Range: 15 to 20 Tons
- Recommended Value For Use: 20 Tons
Type of Bearing Soil - Weather or Broken Bedrock of any Kind except highly Argillaceous Rock (Shale). RQD Less Than 25
Consistency in Place - Soft Rock
Allowable Bearing Pressure (Tons Per Square Feet)
- Range: 8 to 12 Tons
- Recommended Value For Use: 10 Tons
Type of Bearing Soil - Compaction Shale or Other Highly Argillaceous Rock in Sound Condition
Consistency in Place - Soft Rock
Allowable Bearing Pressure (Tons Per Square Feet)
- Range: 8 to 12 Tons
- Recommended Value For Use: 10 Tons
Type of Bearing Soil - Well Graded Mixture or Fine and Coarse-Grain Soil: Glacial Till, Hardpan, Boulder Clay
Consistency in Place - Very Compact
Allowable Bearing Pressure (Tons Per Square Feet)
- Range: 8 to 12 Tons
- Recommended Value For Use: 10 Tons
Type of Bearing Soil - Gravel, Gravel-Sand Mixtures, Boulder Gravel Mixtures
Consistency in Place - Very Compact Medium to Compact Loose
Allowable Bearing Pressure (Tons Per Square Feet)
Range:
- 6 to 10 Tons
- 4 to 7 Tons
- 2 to 6 Tons
Recommended Value For Use:
- 7 Tons
- 5 Tons
- 3 Tons
Type of Bearing Soil - Coarse to Medium Sand, Sand with Little Gravel
Consistency in Place - Ver Compact Medium to Compact Loose
Allowable Bearing Pressure (Tons Per Square Feet)
Range:
- 4 to 6 Tons
- 2 to 4 Tons
- 1 to 3 Tons
Recommended Value For Use:
- 4 Tons
- 3 Tons
- 1.5 Tons
Type of Bearing Soil - Fine to Medium Sand, Silty or Clayey Medium to Coarse Sand
Consistency in Place - Very Compact Medium to Compact Loose
Allowable Bearing Pressure (Tons Per Square Feet)
Range:
- 3 to 5 Tons
- 2 to 4 Tons
- 1 to 2 Tons
Recommended Value For Use:
- 3 Tons
- 2.5 Tons
- 1.5 Tons
Type of Bearing Soil - Homogenous Inorganic Clay, Sandy or Silty Clay (CL, CH)
Consistency in Place - Very Stiff to Hard Medium to Stiff Soft
Allowable Bearing Pressure (Tons Per Square Feet)
Range:
- 3 to 6 Tons
- 1 to 3 Tons
- 0.5 to 1 Tons
Recommended Value For Use:
- 4 Tons
- 2 Tons
- 0.5 Tons
Type of Bearing Soil - Gravel, Gravel-Sand Mixtures, Boulder Gravel Mixtures (SW, SP,SW, SP)
Consistency in Place - Very Stiff to Hard Medium to Stiff Soft
Allowable Bearing Pressure (Tons Per Square Feet)
Range:
- 2 to 4 Tons
- 1 to 3 Tons
- 0.5 to 1 Tons
Recommended Value For Use:
- 3 Tons
- 1.5 Tons
- 0.5 Tons
CATERPILLAR TRACK GRADING EQUIPMENT
JOB REQUIREMENT -
- When Cuts Are (+3 or -3" )
- When Job Are 3,000 Sq. Feet or Daily Completion are 3,000 Sq. Feet
- When in Parking Lots with Fresh Pour Curbs
- When Grades are 1' Offset to Save Material
- When Soil Recommended Value of Use is 1,000 lbs. PSI
CATERPILLAR 299 D3 XE COMPACT TRACK LOADER w/DOZER BLADE
DIMENSIONS
- Length: 125.5"
- Width: 76"
- Tracks Length: 89.4"
- Tracks Width: 15.7"
- Height: 158.7"
- Weight: 11,756 lbs.
JOB AND SOIL REQUIREMENTS
- PSI Rating: 1,204.5 lbs.PSI
- Job Bidding Size: 658 Square Feet or Greater
- Blade Capacity - 0.7 Cubit FYards
CATERPILLAR D1 LGP WIDE TRACK DOZER
DIMENSIONS:
- Length: 167.8"
- Width: 94.9"
- Tracks Length: 89"
- Tracks Width: 30"
- Height: 108.9"
- Weight: 21,103 lbs.
JOB AND SOIL REQUIREMENTS
- PSI Rating : 1,140 lbs. PSI
- Job Bidding Size: 1,104 Square Feet or Greater
- Blade Capacity: 2.17 Cubic Yards
CATERPILLAR D6 LGP
DIMENSIONS:
- Length: 215.2"
- Width: 160"
- Tracks Length: 128.9"
- Tracks Width: 39"
- Height: 126.6"
- Weight: 47,754 lbs.
JOB AND SOIL REQUIREMENTS
- PSI Rating : 1,373 lbs. PSI
- Job Bidding Size: 2,390 Square Feet or Greater
- Blade Capacity: 5.0 Cubic Yards
CATERPILLAR SMART GRADING EQUIPMENT
When Job Cuts Are - (+1.75" or -1.75")
When Jobs Are - 15,000 Sq. Feet Or Daily Allowance Are Required to Meet
- Used On Haul Roads
- Used on Open Jobsites
- Used on Cul-d-Sac or Roundabouts
- Used on Building Pads
- Used on Runways and Seaport
CATERPILLAR 299 D3 XE COMPACT TRACK LOADER w/GB124 GRADE BLADE WITH WINGS & TOPCON 3D-MC MACHINE CONTROL
DIMENSIONS
- Length: 173.5"
- Blade Length: 8.5'
- Blade Height: 17"
- Blade Rotation: 205 Degrees
- Max Cutting Depth: 4"
- Blade Ground Clearance (Over Water Boxes): 6"
- Blade Tilt Angle: 15 Degrees
- Width: 96"
- Tracks Length: 89.4"
- Tracks Width: 15.7"
- Height: 158.7"
- Weight: 12,401 lbs.
JOB AND SOIL REQUIREMENTS
- PSI Rating: 1,270.65 lbs.PSI
- Job Bidding Size: 1,658 Square Feet or Greater
- Blade Capacity - 0.4 Cubic Yards
CATERPILLAR 120 GC MOTOR GRADER
DIMENSIONS:
- Top Speed Forward: 25.8 mph
- Top Speed Reverse: 16.3 mph
- Total Gears - 9 Speed
- Forward Gears - 6 Speed
- Reverse Gears - 3 Speed
- Tires: 24" Michelin
- Clutch Type: Hydraulic
- Length: 426.3"
- Width: 98.1"
- Spacing Between Tandem Axles: 59.4"
- Wheelbase: 229.6"
- Height: 131.8"
- Weight: 27,646 lbs.
JOB AND SOIL REQUIREMENTS
- Tire Contact Patch PSI Rating: 2,303.83 lbs. PSI
- Job Bidding Size: 7,255.3 Square Feet or Greater
- Blade Capacity: 1.1 Cubic Yards
CATERPILLAR 16GC MOTOR GRADER
DIMENSIONS:
- Top Speed Forward: 32.1 mph
- Top Speed Reverse: 25.4 mph
- Total Gears: 14 Speed
- Forward Gears: 8 Speed
- Reverse Gears: 6 Speed
- Tires: Bridgestone 23.5R25 Radial L3 VJT
- Clutch: Hydraulic
- Length: 463.8"
- Width: 130.7"
- Spacing Between Tandem Axles: 72.5"
- Wheelbase: 273.9"
- Height: 139.3"
- Weight: 70,127 lbs.
JOB AND SOIL REQUIREMENTS
- Tire Contact Patch PSI Rating : 15,843.9 lbs. PSI
- Job Bidding Size: 10,524 Square Feet or Greater
- Blade Capacity: 1.5 Cubic Yards
CATERPILLAR EXCAVATOR GRADING
When Job Cuts Are - (+4" or -4")
When Jobs Are - 117 Cubic Yards or More Dirt to be Removed in 100' or less
- Used Around Utilities Boxes
- Used on Virgin Ground
- Used on Recycling and Paving
- Used on Ditch Grading and Short Steep Slopes
- Used on Runways and Seaport
- Used on Brick Paving & Concrete
- Used in Scarifying Hard Ground
CATERPILLAR 305 CR TIER 3 w/ROPS MINI EXCAVATOR
DIMENSIONS
- Length: 210.2"
- Blade Width: 78"
- Blade Height: 15.7"
- Angle Blade: 25 Degrees
- Max Dig Depth: 144.5"
- Vertical Wall: 100.8"
- Width: 78"
- Tracks Length: 101.8"
- Tracks Width: 15.7"
- Height: 100.4"
- Weight: 12,688 lbs.
JOB AND SOIL REQUIREMENTS
- PSI Rating: 1,144 lbs.PSI
- Job Bidding Size: 1,137 Square Feet
CATERPILLAR 318 D2 L SMALL EXCAVATOR
DIMENSIONS:
- Ground Clearance: 1'6"
- Tracks Length: 13'
- Quick Coupler Bucket Capacity - 1.19 Cubic Yards
- Vertical Wall: 16'10"
- Digging Depth: 20'
- Length: 28'
- Width: 9'5"
- Shoes: 31"
- Height: 9'11""
- Weight: 39,250 lbs.
JOB AND SOIL REQUIREMENTS
- PSI Rating : 1,207.7 lbs. PSI
- Job Bidding Size: 2,660 Square Feet or Greater
CATERPILLAR 333 MEDIUM EXCAVATOR
DIMENSIONS:
- Ground Clearance: 1.6'
- Tracks Length: 15.9'
- Quick Coupler Bucket Capacity: 2.62 Cubic Yards
- Vertical Wall: 20.5'
- Digging Depth: 24.2'
- Length: 34.3'
- Width: 11'
- Shoes: 31"
- Height: 10'
- Weight: 70,800 lbs.
JOB AND SOIL REQUIREMENTS
- PSI Rating : 1,781lbs. PSI
- Job Bidding Size: 3,773 Square Feet or Greater
LEEBOY AND CASE CONSTRUCTION ASSOCIATED WITH BRICK PAVING, CONCRETE & ASPHALT PAVING
When Asphalt Paving Jobs - 2,500 Sq. Feet or Less
When Brick Paving Jobs - 225 Sq. Feet or More
When Concrete Jobs - 125 Sq. Feet or More
- Used in Sub-Division Paving and Driveways
- Used on Commercial Parking Lots
- Used on Patio Decks
- Used on Sidewalks
LEEBOY 5300B ASPHALT PAVER
DIMENSIONS
- Length: 15'5"
- Width: 9'7"
- Height: 5'9"
- Hopper Capacity: 7 Tons
- Paving Width: 7'
- Paving Depth: 6"
- Tracks Length: 5'1"
- Tracks Widths: 7"
- Paving Speed: 151' (11.74 Tons per Minute)
- Height: 100.4"
- Weight: 12,700 lbs.
JOB AND SOIL REQUIREMENTS
- PSI Rating: 3,110 lbs.PSI
- Job Bidding Size: 20 Tons or More
CASE 580 SUPER N WT CONSTRUCTION KING BACKHOE LOADER w/CLAM SHELL BUCKET AND SIDE DUMP
DIMENSIONS:
- Transmission: 8 Speed
- Forward Gears: 4
- Reverse Gears: 4
- Clutch: Hydraulic
- Drive: 4wd
- Front Tires: 18"
- Rear Tires: 24"
- Front Bucket: 1.2 Cubic Yards
- Rear Bucket (36"): 0.36 Cubic Yards
- Wheelbase: 84.5"
- Length: 23'1"
- Width: 8'6"
- Digging Depth: 18'
- Weight: 20,760 lbs.
JOB AND SOIL REQUIREMENTS
- Tires Contact Patch PSI Rating : 3,460 lbs. PSI
- Job Bidding Size: 20 Tons or Less (I-5 Top / 50 Ton Base) Square Feet or Greater
LEEBOY BR48R ASPHALT ROLLER
DIMENSIONS:
- Length 8'5"
- Width: 5'1"
- Height: 8' (ROPS)
- Turning Radius: 8'6"
- Travel Speed: 26.2 mph
- Compaction Width: 60"
- Water Tank: 53 Gallons
- Weight: 5,546 lbs.
JOB AND SOIL REQUIREMENTS
- Drum PSI Rating : 2,218 lbs. PSI
- Job Bidding Size: No Restrictions
POWERSCREEN ROCK CRUSHER, KOMATSU EXCAVATORS RECYCLING
When Recycling Jobs Are Required - 100+ Tons
Jobs Type - When all Material Recycled Are Used as Stones on Existing Jobs Sites to Reduce Customer Cost
- Used in Sub-Division Paving and Driveways
- Used on Commercial Parking Lots
- Used on Sidewalks
- Used on Curbs
- Used on Roads
POWERSCREEN TRAKPACTOR 320 SR RECYCLING MATERIALS (Asphalt, Concrete, Wood, Rocks, Etc.)
OUTPUT PONTENTIAL - 320 Tons Per Minute
- Concrete - 2.65 Cubic Yards per Minute (10,600 lbs. )
- Blue Rock - 3 Cubic Yards per Minute( 8,400 lbs.)
- Asphalt - 2.65 Cubic Yards Per Minute (10,600 lbs.)
DIMENSIONS
TRANSPORT DIMENSIONS
- Width - 8.5'
- Length - 48'6"
- Height - 11'4"
WORKING DIMENSION
- Width - 19'1"
- Length - 56'6"
- Height - 15'5"
WEIGHT - 80,601 (40.3 Tons)
HOPPER
- Length - 13'3"
- Width - 6'11"
- Capacity - 4.7 Cubic Yards
FEEDER
- Length - 12'8"
- Width - 6'11"
RECIRCULATING CONVEYOR
- Width - 19'7"
POWER UNIT-
- Engine - Cat C9 Acert 261Kw Tier 3 / Stage 3A
- Fuel Capacity - 132 Gallons
PRODUCT CONVEYOR
- Width - 39"
- Discharge Height -9'7"
FINES CONVEYOR
- Width - 39"
- Discharge Height - 9'7"
POST-SCREEN (2 Deck Screen box)
- Length - 11'
- Width - 5'
TRACKS
- Width - 15.7"
- Length - 12'6"
CRUSHER (Twin Apron, 4 Bar Impact Crusher)
BY PASS CONVEYOR
- Width - 26"
- Discharge Height - 12'2"
JOB AND SOIL REQUIREMENTS
- PSI Rating: 4,929 lbs.PSI
JOB BIDDING SIZE: 1,280 Tons or More
- Concrete - 640 Cubic Yards
- Blue Rock - 914 Cubic Yards
- Asphalt - 640 Cubic Yards
KOMATSU PC900 LC-11 EXCAVATOR LOADING RECYCLING MATERIALS (Asphalt, Concrete, Wood, Rocks, Etc.)
TRANSPORT REMOVED PARTS
- Arm Assembly - 11,023 lbs.
- Counter Weight - 28,175 lbs.
- Handrails, Steps, Walkway, Etc. - 1,521 lbs.
- Machine Weight - 154,963 lbs.
- Transport Width - 14'
- Transport Length - 48'6"
- Transport Height - 12'10"
DIMENSIONS:
- Bucket Capacity - 3.7 to 8 Cubic Yards
- Operating Weight - 204,148 lbs.
- Ground Clearance - 2'11"
- Tail Swing Radius - 15'2"
TRACKS
- Length - 20'9"
- Width - 35"
DIGGING SPECS
- Digging Depth - 35'4"
- Vertical Wall Depth - 28'8"
JOB AND SOIL REQUIREMENTS
PSI Rating:
- Transport on Globe 80-Ton PSI Rating on Trailer - 9,959 lbs. PSI
- Soil Rating (PSI) - 13,120 lbs. PSI
JOB BIDDING SIZE:
- Square Yards - 128,000 Square Yards
- Concrete (6") - 4,260 Cubic Yards
- Blue Rock (Blasted Rock 6" or More - 6,093 Cubic Yards
- Asphalt - 4,260 Cubic Yards
KOMATSO PC360LC-11 DEMOLITION EXCAVATOR WITH SHEARS AND HAMMER ATTACHMENT
DIMENSIONS:
- Operating Weight -80,547 lbs.
- Bucket Capacity - 0.89 to 2.56 Cubic Yards
- Height - 10'11"
- Width - 11'3"
- Ground Clearance - 1'8"
- Tail Swing Radius - 11'4"
- Max. Digging Depth - 26'7"
- Vertical Wall Depth - 23'11"
TRACKS
- Width - 33.5"
- Length - 13'3"
JOB AND SOIL REQUIREMENTS
- PSI Rating : 2,178 lbs. PSI
JOB BIDDING SIZE:
- Concrete - 491 Tons
- Blue Rock - 343 Tons
- Asphalt - 491 Tons
