Trailer Specs
Axle Limits
Tractor - Up to 66,000 lbs.
- Steer Axle - 13,600 lbs, to 20,000 lbs.
- Tractor Lift Axle - 13,500 lbs. to 23,000 lbs.
- Tractor Drive Axle - 40,000 lbs. to 46,000 lbs.
Jeep Axles (Single to Double Tridem Axles) - Up to 150,000 lbs.
- Single Axle - 25,000 lbs.
- Tandem Axle - 50,000 lbs.
- Tridem Axle - 75,000 lbs.
- Quad Axle - 100,000 lbs.
- Triple 16 Axles - 100,000 lbs.
- Cinco Axles - 125,000 lbs.
- Triple 24 Axles - 150,000 lbs.
Trailer Axles (Single to Double Tridem Axles) - Up to 150,000 lbs.
- Single Axle - 25,000 lbs.
- Tandem Axle - 50,000 lbs.
- Tridem Axle - 75,000 lbs.
- Quad Axle - 100,000 lbs.
- Triple 16 Axles - 100,000 lbs.
- Cinco Axles - 125,000 lbs.
- Triple 24 Axles - 150,000 lbs.
Booster Axles (Single to Double Tridem Axles) - Up to 150,000 lbs.
- Single Axle - 25,000 lbs.
- Tandem Axle - 50,000 lbs.
- Tridem Axle - 75,000 lbs.
- Quad Axle - 100,000 lbs.
- Triple 16 Axles - 100,000 lbs.
- Cinco Axles - 125,000 lbs.
- Triple 24 Axles - 150,000 lbs.
- Manufacturer Gross Combination Weight Rating - Up to 366,000 lbs.
- Average Weight Per Axle - 7,038 lbs. to 23,500 lbs. Weight Per Foot Up to 297’ Length - 1,231 lbs. Per foot
- Max. Axle Spread - 18’ Spacing Up to 74’ Spacing Between Axles Group
- # of Axles Required - 6 Axles Min. Between Two Axles Group
NORTH CAROLINA DEPARTMENT OF TRANSPORTATION MAX. PERMIT WEIGHT PER AXLE
TRUCKS OR TRACTOR RATINGS
- Single or Steer Axle - Up to 20,000 lbs.
- Tandem Axle - Up to 50,000 lbs.
- Tridem Axle - 60,000 lbs.
- Quad Axle - 68,000 lbs.
TRAILERS RATINGS
Average Weight Per Axle - 16,000 lbs. per axle
- Total Weight Allowed Under SuperLoad Transport - 192,000 lbs
- Axle Spread - 32’ Spacing Between Axles Group
- # of Axles Required - 12 Axles
NO PERMIT OR NO RESTRICTIONS FOR EQUIPMENT ON LEGAL DIMENSIONS OF SHIPMENT
- MAX. LEGAL WIDTH w/o PERMITS - 8.5’
- MAX. LEGAL LENGTH w/o PERMITS - 53’
- MAX. LEGAL HEIGHT w/o PERMITS
- Flatbed - 9.25' (111")
- Step Deck - 10.5' (126")
- Conestoga (Flatbed) - 9' (108")
- Conestoga (Step Deck) - 10.25' (123")
- Conestoga (Gooseneck) - 10.25' (123")
- Mini Deck - 12.5' (150")
- Drop Side Rail Lowboy - 12' (144")
- Flat Deck Lowboy - 11.5' (138")
- Beam Lowboy - 13' (156")
NO PERMIT WITHOUT DRIVING RESTRICTIONS ON EQUIPMENT FOR LEGAL DIMENSIONS OF SHIPMENT
- MAX. LEGAL DRIVING WIDTH RESTRICTION - 9.5' (1’ Overhang )
- MAX. LEGAL DRIVING LENGTH RESTRICTIONS - 2’ Overhang
- MAX. LEGAL DRIVING HEIGHT RESTRICTIONS - 14’ Tall
PERMIT VEHICLE WITH PILOT CAR ASSESSMENT OR APPROVE ROUTE PLAN DRIVING
- MIN. LEGAL DRIVING WIDTH w/APPROVED PILOT CAR - 10’
- MIN. LEGAL DRIVING LENGTH w/APPROVED PILOT FOLLOW PILOT CAR - 85’ (Total Length)
- MIN. LEGAL DRIVING HEIGHT w/APPROVED PILOT CAR WITH HEIGHT POLE - 14’1”
- MIN. LEGAL DRIVING WEIGHT w/APPROVED POLICE ESCORT - 160,000 lbs. Over Bridges
RAMP LOADING EQUIPMENT & VEHICLES REQUIREMENT
DECK HEIGHT
- Flatbed - 4.25' (51")
- Step Deck - 3' (36")
- Gooseneck - 3' (36")
- Conestoga - 36" to 51"
- Mini Deck - 12" (1')
- Lowboy - 2' (24")
ALL-ALUMINUM HEAVY-DUTY RAMPS SPECS
- Flatbed - ([6 Ramps] 42’ Length ’x 20” Width w/Four Ramp Stands - 8" length = 1" Rise)
- Step Deck - ([4 Ramps] 28’ Length ’x 20” Width w/Four Ramp Stands - 9" length = 1" Rise)
Flatbed Specs
2027 EXTREME XP75 ALL ALUMINUM FLATBED - 9,500 lbs. TARE WEIGHT
Tractor & Flatbed Trailer
- Equipment Weight Rating
- Tractor (3 Axles @ 29’ Spacing) - 57,500 lbs.
- Trailer (3 Axles @ 41’ Spacing) - 60,000 lbs.
- Combination (5 Axles) - 117,500 lbs. (Pending Spacing & Axles Rating)
- Axle Weight Rating
- Steer Axle Rating - 20,000 lbs.
- Drive Axle Rating - 46,000 lbs.
- Split Axle Front - 25,000 lbs.
- Split Axle Rear - 25,000 lbs.
- TOTAL RATING - 110,000 lbs.
- Average Axle Rating - 22,000 lbs.
- Tare Weight Limitations - 32,973 lbs. Empty
- Length - 73’
- Steer Axle Hub to Last Trailer Axle Hub Spacing - 65’
- Spacing Per Foot - 451 lbs.
- 5 Axles Weight Per Axle - 6,594 lbs. per axle
- Shipment Weight Legal Limitation - 47,027 lbs.
- Length - 73’
- Spacing Per Foot - 644 lbs.
- 5 Axles Weight Per Axle - 9,405 lbs. per axle
- Shipment Weight Permit Limitations - 77,027 lbs.
- Length - 73’
- Spacing Per Foot - 1,055 lbs.
- 5 Axles Weight Per Axle - 15,405 lbs. per axle
- Heavy Weight Limitations - 110,000 lbs. Permitted
- Length - 73’
- Spacing Per Foot - 1.506 lbs.
- 5 Axles Weight Per Axle - 22,000 lbs. per axle
Step Deck Info
2027 EXTREME XP75 ALL ALUMINUM FLATBED - 9,500 lbs. TARE WEIGHT
Tractor & Step Deck Trailer
- Equipment Weight Rating
- Tractor (3 Axles @ 29’ Spacing) - 57,500 lbs.
- Trailer (4 Axles @ 46’ Spacing ) - 72,500 lbs.
- Combination (5 Axles) - 130,000 lbs. (Pending Spacing & Axles Rating)
- Axle Weight Rating
- Steer Axle Rating - 20,000 lbs.
- Drive Axle Rating - 46,000 lbs.
- Tridem Axle Front - 25,000 lbs.
- Tridem Axle Middle - 25,000 lbs.
- Tridem Axle Rear - 25,000 lbs.
- TOTAL RATING - 141,000 lbs.
- Average Axle Rating - 23,500 lbs.
- Tare Weight Limitations - 36,973 lbs. Empty
- Length - 78’
- Steer Axle Hub to Last Trailer Axle Hub Spacing - 68’
- Spacing Per Foot - 474 lbs.
- 6 Axles Weight Per Axle - 6,162 lbs. per axle
- Shipment Weight Legal Limitation - 43,027 lbs.
- Length- 78’
- Spacing Per Foot - 551 lbs.
- 6 Axles Weight Per Axle - 7,171 lbs. per axle
- Shipment Weight Permit Limitations - 93,027 lbs.
- Length- 78’
- Spacing Per Foot - 1,192 lbs.
- 6 Axles Weight Per Axle - 15,504 lbs. per axle
- Heavy Weight Limitations - 130,000 lbs. Permitted
- Length - 78’
- Spacing Per Foot - 1.666 lbs.
- 6 Axles Weight Per Axle - 21,666 lbs. per axle
Fleet Reliability
Premier Peterbilt 389
Reliable service to keep your fleet running smoothly.
Heavy Haul Logistics
Shipment Specs
Open deck trailers (flatbeds, step-decks, RGNs) are used to ship oversized, heavy, or irregularly shaped freight like heavy machinery (bulldozers, cranes, excavators), construction materials (steel beams, lumber, pipes), agricultural equipment (tractors, combines), wind turbine blades, and large industrial components, requiring securements like straps, chains, and tarps for protection and safety during transport. Examples range from moving farm tractors on flatbeds to driving massive cranes onto RGNs .
FLATBED SHIPMENT DIMENSIONS
EQUIPMENT - CAT AP-455 Paver
LENGTH - 19'
WIDTH - 10.75'
HEIGHT - 8.6'
WEIGHT - 31,533 lbs.
WEIGHT PER FOOT - 1,659.6 lbs. per foot
TRAILER REQUIRED - CAT AP-455 Paver - FLATBED Need Loading Assistance - 24’ Spacing between Drive and Trailer Axles
EQUIPMENT - CAT D5 Dozer
LENGTH - 15.3'
WIDTH - 8.2'
HEIGHT -7.7'
WEIGHT - 37,875 lbs.
WEIGHT PER FOOT - 2,475.4 lbs. per foot
TRAILER REQUIRED - FLATBED Ramp Loading -16.1’ Spacing between Drive and Trailer Axles
