NAOMI JEANETTE ROBINSON TRUCKING

1444 Jefferys Road #580

Rocky Mount, NC 27804

Toll Free Phone# (844)415-3410

Office# (252)877-2108

Cell# (252)903-3751

Fax# (252)877-2117

info@njrtruckingllc.com

https://www.njrtruckingllc.com

CARRIER PROFILE

COMPLETE LEGAL NAME: __Naomi Jeanette Robinson Trucking LLC

NAME / TITLE: __Tariq Tony Robinson____
SHIPPING ADDRESS: __1444 Jeffreys Road #580 / Rocky Mount, NC 27804_
DISPATCH DAY PHONE: __(252)985-1650___
NIGHT PHONE: __(252)930-3321
FAX: __(252)446-6645
FMCSA DOT OPERATING AUTHORITY: ____Yes____
E-MAIL ADDRESS: __njrtruckingllc@gmail.com____
I WOULD APPRECIATE IF YOU WOULD SEND AVAILABLE FREIGHT EACH DAY BY:__E-mail__

  DRIVING LOCALITY REQUIRED:

HAVE OWN AUTHORITY: Yes

• Haul General Freight: ____Yes____
  • Dry Van Trailer (Hide USDOT#)
  • Refrigerated Trailer (Hide USDOT#)
• Household Goods: _____Not Under My USDOT#___
  • Have to Hide USDOT# to Haul Households goods
  • Leased on to N.J.R. Logistics Group
• Vehicles: __Yes______
  • Have to Hide USDOT# to Haul Vehicles
  • Leased on to N.J.R. Logistics Group
• Building Material: ___Yes_____
  • Flatbed Trailer __35% Usage
  • Step Deck Trailer __15% Usage
  • Conestoga Trailer _50% of Freight
• Heavy Haul: ____Yes____
  • Step Deck (Tri Axle) Trailer __55,750 lbs. Capacity
  • Mini Deck Deck (3+1) Trailer __73,500 lbs. Capacity
  • 65-Ton (3+3+2) Lowboy _115,000 lbs. Capacity
  • 85-Ton (3+3+3) __120,000 lbs. Capacity
  • 100-Ton (3+3+3+3) _172,500 lbs. Capacity
• Specialized: ____Yes____
  • Extendable Flatbed Trailer  9.25' Legal Height Capacity
  • Step Deck (Tri Axle) Trailer __10.5' Legal Height Capacity
  • Mini Deck Deck (3+1) Trailer __12.5' Legal Height Capacity
  • 65 -Ton (3+3+2) Lowboy - 11.5. Legal Height Capacity
  • 100-Ton (3+3+3+3) _11' Legal Height Capacity
• Doubles Endorsement ___Yes_____
• Triples Endorsement ___Yes_____
• Hazmat _____Yes___
• Passenger: ___Yes_____

JANUARY THRU MARCH DRIVING PREFERRED LOCATION:

1. Time Zone: ____Eastern and Central____
2. Points North Boundary:__Interstate-40______
3. Points South Boundary ____N/a____
4. Points West Boundary____Interstate-65____
5. Points East Boundary ____N/a____
6. Trailer(s) Preferred: ___Conestoga, Refrigerated_____

APRIL THRU JUNE DRIVING PREFERRED LOCATION

1. Time Zone: __Eastern, Central, Mountain_____
2. Points North Boundary:___Interstate-90_____
3. Points South Boundary ___N/a_____
4. Points West Boundary __Interstate______
5. Points East Boundary ___N/a_____
6. Trailers Preferred: _Schnable System, Wind Blade, 55-Ton Lowboy, 62.5-Ton Lowboy, 85-Ton Lowboy_______

JULY THRU SEPTEMBER DRIVING PREFERRED LOCATION

1. Time Zone: ___Eastern, Central, Mountain, Pacific_____
2. Points North Boundary:__Canada______
3. Points South Boundary___USA & Mexico Line_____
4. Points West Boundary_Pacific Coast_______
5. Points East Boundary___Atlantic Coast_____
6. Trailers Preferred: _Flatbed & Step Deck_______

OCTOBER THRU DECEMBER DRIVING PREFERRED LOCATION

1. Time Zone: ___Eastern, Central, Mountain & Pacific_____
2. Points North Boundary:____Canada____
3. Points South Boundary____Mexico____
4. Points West Boundary____Pacific Ocean____
5. Points East Boundary___Atlantic Ocean_____
6. Trailer(s) Preferred: ___Open Transporter, Enclosed Transporter, Moving Van_______
7. Operations Quarter: ___Leased on_______

NAOMI JEANETTE ROBINSON TRUCKING

1444 Jefferys Road #580

Rocky Mount, NC 27804

Toll Free Phone# (844)415-3410

Office# (252)877-2108

Cell# (252)903-3751

Fax# (252)877-2117

info@njrtruckingllc.com

https://www.njrtruckingllc.com

CARRIER PROFILE

COMPLETE LEGAL NAME: __Naomi Jeanette Robinson Trucking LLC

NAME / TITLE: __Tariq Tony Robinson____
SHIPPING ADDRESS: __1444 Jeffreys Road #580 / Rocky Mount, NC 27804_
DISPATCH DAY PHONE: __(252)985-1650___
NIGHT PHONE: __(252)930-3321
FAX: __(252)446-6645
FMCSA DOT OPERATING AUTHORITY: ____Yes____
E-MAIL ADDRESS: __njrtruckingllc@gmail.com____
I WOULD APPRECIATE IF YOU WOULD SEND AVAILABLE FREIGHT EACH DAY BY:__E-mail__

1. NORTH CAROLINA MAX. PERMIT WEIGHT PER AXLE

• TRACTOR RATINGS
  • Steer Axle - Up to 20,000 lbs.
  • Tractor Tandem Drive - Up to 50,000 lbs.
  • Tractor Tridem Axle - 60,000 lbs.
  • Tractor Quad Axle - 68,000 lbs.

1. Trailer Tridem - 60,000 lbs.  Per Axle
2. Gross Combination Weight Rating - 140,000 lbs.
3. Average Weight Per Axle - 20,000 lbs. per axle(not perishable)

• Weight Per Foot (75’ Total Length) - 1,866 lbs.
• Max. Axle Spread - 21’ Spacing
• # of Axles Required - 8 Axles

1. FEDERAL MAX. PERMIT WEIGHT PER AXLE

• Steer Axle Hub to Lift Axle Hub (22’ Spacing) - 40,000 lbs.
• Lift Axle Hub to Drive Axle Front Hub (4.5’ Spacing)  - 34,000 lbs.
• Drive Axle Hub Front to Drive Axle Hub Rear (4.5’ Spacing) - 34,000 lbs.
• Drive Axle Hub Rear to Trailer Tridem Axle Hub Front (30’ Spacing) - 40,000 lbs.
• Trailer Tridem Axle Hub Front to Trailer Tridem Axle Hub Center (6’ Spacing) - 34,000 lbs.
• Trailer Tridem Axle Hub Center to Trailer Axle Hub Rear (6’ Spacing) - 34,000 lbs.
• Gross Combination Weight Rating - 216,000 lbs.
• Average Weight Per Axle - 30,857 lbs. Per axle (not perishable)
• Weight Per Foot (75’ Total Length) - 2,880 lbs.
• Max. Axle Spread - 13’ Spacing
• # of Axles Required - 12 Axles

1. TOTAL LENGTH OF VEHICLE
   1. Tractor (Bumper to Bumper) - 447” (37’)
   2. Trailer (Front to Rear) - 636” (53’)
   3. Fifth Wheel (Front Bumper to Locking Jaw) - 356” (29.6’)
   4. Kingpin Setting (Front to Center of Kingpin) - 30” (2.5’)
   5. Front of Trailer to Last Drive Axle Hub - 90” (7.5’)
   6. Total Length (Bumper to Bumper) - 901.2” (75.1’)
2. TRACTOR TARE WEIGHT - 27,000 lbs.
3. TRAILER TARE WEIGHT (with ramps & winches) - 13,000 lbs.
4. TRACTOR & TRAILER TARE WEIGHT - 40,000 lbs.
5. TARE WEIGHT PER FOOT (75’ Length) - 533 lbs. Per Foot
6. PERMIT WEIGHT PER FOOT - 1,700 lbs. Per Foot
7. WEIGHT OF SHIPMENT
   • Legal Weight (80,000 lbs.) - 40,000 lbs.
   •

   • Permit Weight (127,500 lbs.) - 87,500 lbs.

CONTRACT REQUIREMENTS

1. GROSS VEHICLE WEIGHT RATING

• Tri Axle Tractor - 61,500 lbs.
• Tridem Axle Trailer - 66,000 lbs.

1. TRACTOR & TRAILER GROSS WEIGHT RATING

• Tractor & Trailer (7-Axles) - 127,500 lbs.

1. Weight Per Axle - 18,214 lbs. Per axle

• Weight Per Foot (75’ Total Length) - 1,700 lbs.
• Max. Axle Spread - 23’ Spacing
• # of Axles Required - 7 Axles

1. TRACTOR & TRAILER AMOUNT OF AXLES

• Tractor - 3 to 4 Axles
• Trailer - 2 to 48 Axles
• Total Axles - 5 up to 52 Axles

1. MANUFACTURER  MAX. PERMIT WEIGHT PER AXLE

• Tractor - Up to 66,000 lbs.
  • Steer Axle - 13,600 lbs, to 20,000 lbs.
  • Tractor Lift Axle - 13,500 lbs. to 23,000 lbs.
  • Tractor Drive Axle - 40,000 lbs. to 46,000 lbs.

1. Jeep Axles (Single to Double Tridem Axles) - Up to 150,000 lbs.

• Single Axle - 25,000 lbs.
• Tandem Axle - 50,000 lbs.
• Tridem Axle - 75,000 lbs.
• Quad Axle - 100,000 lbs.
• Triple 16 Axles - 100,000 lbs.
• Cinco Axles - 125,000 lbs.
• Triple 24 Axles - 150,000 lbs.

1. Trailer Axles (Single to Double Tridem Axles) - Up to 150,000 lbs.

• Single Axle - 25,000 lbs.
• Tandem Axle - 50,000 lbs.
• Tridem Axle - 75,000 lbs.
• Quad Axle - 100,000 lbs.
• Triple 16 Axles - 100,000 lbs.
• Cinco Axles - 125,000 lbs.
• Triple 24 Axles - 150,000 lbs.

1. Booster Axles (Single to Double Tridem Axles) - Up to 150,000 lbs.

• Single Axle - 25,000 lbs.
• Tandem Axle - 50,000 lbs.
• Tridem Axle - 75,000 lbs.
• Quad Axle - 100,000 lbs.
• Triple 16 Axles - 100,000 lbs.
• Cinco Axles - 125,000 lbs.
• Triple 24 Axles - 150,000 lbs.

1. Manufacturer Gross Combination Weight Rating - Up to 366,000 lbs.
2. Average Weight Per Axle - 7,038 lbs. to 23,500 lbs.

• Weight Per Foot
• Up to 297’ Length - 1,231 lbs. Per foot
• Max. Axle Spread - 18’ Spacing
• Up to 74’ Spacing Between Axles Group
• # of Axles Required -
• 6 Axles Min. Between Two Axles Group

NAOMI JEANETTE ROBINSON TRUCKING

1444 Jefferys Road #580

Rocky Mount, NC 27804

Toll Free Phone# (844)415-3410

Office# (252)877-2108

Cell# (252)903-3751

Fax# (252)877-2117

info@njrtruckingllc.com

https://www.njrtruckingllc.com

CARRIER PROFILE

COMPLETE LEGAL NAME: __Naomi Jeanette Robinson Trucking LLC

NAME / TITLE: __Tariq Tony Robinson____
SHIPPING ADDRESS: __1444 Jeffreys Road #580 / Rocky Mount, NC 27804_
DISPATCH DAY PHONE: __(252)985-1650___
NIGHT PHONE: __(252)930-3321
FAX: __(252)446-6645
FMCSA DOT OPERATING AUTHORITY: ____Yes____
E-MAIL ADDRESS: __njrtruckingllc@gmail.com____
I WOULD APPRECIATE IF YOU WOULD SEND AVAILABLE FREIGHT EACH DAY BY:__E-mail__

JANUARY THRU MARCH DRIVING PREFERRED LOCATION:

1. Time Zone: ____Eastern and Central____
2. Points North Boundary:__Interstate-40______
3. Points South Boundary ____N/a____
4. Points West Boundary____Interstate-65____
5. Points East Boundary ____N/a____
6. Trailer(s) Preferred: ___Conestoga, Refrigerated_____

APRIL THRU JUNE DRIVING PREFERRED LOCATION

1. Time Zone: __Eastern, Central, Mountain_____
2. Points North Boundary:___Interstate-90_____
3. Points South Boundary ___N/a_____
4. Points West Boundary __Interstate______
5. Points East Boundary ___N/a_____
6. Trailers Preferred: _Schnable System, Wind Blade, 55-Ton Lowboy, 62.5-Ton Lowboy, 85-Ton Lowboy_______

JULY THRU SEPTEMBER DRIVING PREFERRED LOCATION

1. Time Zone: ___Eastern, Central, Mountain, Pacific_____
2. Points North Boundary:__Canada______
3. Points South Boundary___USA & Mexico Line_____
4. Points West Boundary_Pacific Coast_______
5. Points East Boundary___Atlantic Coast_____
6. Trailers Preferred: _Flatbed & Step Deck_______

OCTOBER THRU DECEMBER DRIVING PREFERRED LOCATION

1. Time Zone: ___Eastern, Central, Mountain & Pacific_____
2. Points North Boundary:____Canada____
3. Points South Boundary____Mexico____
4. Points West Boundary____Pacific Ocean____
5. Points East Boundary___Atlantic Ocean_____
6. Trailer(s) Preferred: ___Open Transporter, Enclosed Transporter, Moving Van_______
7. Operations Quarter: ___Leased on_______

MINIMUM REQUIREMENTS

COMMODITY SPACE (Cubic Feet)

1. COMMODITY & CUBIC SPACE
   1. Semi Trailer
      1. Commodity Coverage: ______$100,000.00 (General Freight to $4,000,000 (Thousand Ton Crawler or Hydraulic Crane)

Owner Operator Percentage Pay:

1. Commodity Percentage (General Freight)___9.375%
2. Per Load: Base on Amount of Tires, Equipment Dimension, Shipment Dimensions, Permits Requirements to and from
3. Hourly: Base on 9 Hours or Less driving or On-Duty Hours Requirement, ETA, Receiver Location
4. Mileage: Base on Business Daily Rate, Hours On-Duty to Deliver Requirement, Base on Loading and Unloading procedures
5. Weight: Base on Axles Requirement, Based on Tires Required, Base on Driving Restrictions and Hours, Base on Permits
6. Oversize: based on All Above and Route Plans, Equipment Required for Completion, Sub-Contractors on Payroll, Pilot Cars Requirements

DAT Trendlines  Dry Van Mileage - 4,596 Mileage (A week or month to meet [Daily Business Expenses])

1. Weekly Hours of Service - 70 Hours
2. Weekly Driving Hours (9 hours Daily) - 63 Hours
3. Avg. MPH to drive weekly to obtain pay - 72.9 mph
4. Pay Drivers to meet 50 mph Avg. Speed to Make Roads Safe
5. Pay Them Max. 3,150 Miles Weekly
6. Pay Per Mile - $2.98 Min. Wage

DAT Trendlines Flatbed Mileage - 3,780 Miles (A week or month to meet [Daily Business Expenses])

1. Weekly Hours of Service - 70 Hours
2. Weekly Driving Hours (9 hours Daily) - 63 Hours
3. Avg. MPH to drive weekly to obtain pay - 60 mph
4. Pay Drivers to meet 50 mph Avg. Speed to Make Roads Safe
5. Pay Them Max. 3,150 Miles Weekly
6. Pay Per Mile - $2.98 Min. Wage

DAT Trendlines  Reefer Mileage - 3,890 Miles (A week or month to meet [Daily Business Expenses])

1. Weekly Hours of Service - 70 Hours
2. Weekly Driving Hours (9 hours Daily) - 63 Hours
3. Avg. MPH to drive weekly to obtain pay - 61.7 mph
4. Pay Drivers to meet 50 mph Avg. Speed to Make Roads Safe
5. Pay Them Max. 3,150 Miles Weekly
6. Pay Per Mile - $2.98 Min. Wage

USDOT Number

• The requirement of being an Independent Contractor a USDOT number must be obtained to transport hazardous material, drive for passengers, or deliver interstate freight.

Vehicle Inspections

• The Federal Motor Carrier Safety Administration (FMCSA) requires drivers to perform inspections before and after each trip to ensure the vehicle is safe to operate.
• Naomi Jeanette Robinson Logistics Group Requires a Carrier Packet Completed with all the things to protect the safety awareness, equipment, cargo and good business name

State Transportation Permits

• Naomi Jeanette Robinson Logistics Group encourages Intrastate Carriers and some Interstate Carriers to obtain Annual Overweight Permits with surrounding states where you reside.

Commercial liability insurance

• Naomi Jeanette Robinson Logistics Group encourages a min.$7,000,000.00 Liability Coverage is required for heavy haul and Specialized
• Owner Operators need to file proof of commercial automobile liability insurance for each registered vehicle to ensure they are covered in the event of an accident or injury.


1. SELF PAY EXPENSES
   1. Total Cost Annually: _$100,000.00
   2. Total Daily Cost $396.83
   3. Per Mile Rate: $1.00 Per Mile
2. OVER THE ROAD EXPENSES
   1. Total Cost Annually: _$40,152.00
   2. Total Daily Cost $159.53
   3. Per Mile Rate: $0.40 Per Mile
3. MISC. EXPENSES
   1. Total Cost Annually: _$143,046.70_
   2. Total Daily Cost $567.65
   3. Per Mile Rate: $1.43 Per Mile
4. INSURANCE
   1. Total Cost Annually: _$45,000.00__
   2. Total Daily Cost $178.57
   3. Per Mile Rate: $0.45 Per Mile
5. SERVICE & FUEL
   1. Total Cost Annually: _$109,264.71_
   2. Total Daily Cost $443.59
   3. Per Mile Rate: $1.09 Per Mile
6. TIRES & BRAKES
   1. Total Cost Annually: _$34,400.00_
   2. Total Daily Cost $136.51
   3. Per Mile Rate: $0.34 Per Mile
7. BOBTAIL TRACTOR TRI AXLE EXPENSES
   1. Total Annual Expenses (100,000 Miles):  _$471,863.41_
   2. Per Mile_$4.72 Per Mile
   3. Per Hour_$
   4. 208.05 Hourly
   5. Daily_$1,872.47 Daily

PAID ADVANCEMENT FOR TIRES & BRAKES

Total Cost Annually: _$34.400.00__

Per Mile Rate: $0.34Per Mile

TIRES

TRACTOR TIRES AMOUNT - 12

COST PER TIRE - $800.00

TIRES MILEAGE LIFESPAN (Miles) - 30,000

AVERAGE ANNUAL MILEAGE DRIVEN (Miles) - 100,000

COMPLETE TIRE SET REQUIRED ANNUALLY - 3.34

TIRES ANNUAL COST - $32,000.00

BRAKES

TRACTOR BRAKE PADS  AMOUNT - 8

COST PER BRAKE PADS - $300.00

BRAKE PADS MILEAGE LIFESPAN (Miles) - 100,000

AVERAGE ANNUAL MILEAGE DRIVEN (Miles) -100,000

COMPLETE BRAKE PAD SET REQUIRED ANNUALLY - 1

BRAKE PADS ANNUAL COST -$2,400.00

ADVANCEMENT FOR TIRES & BRAKES

Total Cost Annually: _$34,400.00_

Total Daily Cost $136.51

TOTAL MILEAGE DRIVEN (Miles) - 100,000

COST PER MILE (Tires) - $0.32

COST PER MILE (Brakes) - $0.02

TOTAL COST PER MILE - $0.34

TOTAL WORKING DAYS (Days) - 252

TOTAL DAILY COST - $136.51

PAID ADVANCEMENT FOR SERVICE & FUEL

Total Cost Annually: _$109,264.71_

Per Mile Rate: $1.09 Per Mile

ANNUAL COST

SERVICE

SCHEDULE TRACTOR MAINTENANCE AMOUNT - 10 Schedule Services Annually

COST PER ITEM - $1,750.00 Per Service

MILEAGE LIFESPAN (Miles) - 10,000

MILEAGE DRIVEN (Miles) - 100,000

REQUIRED ANNUALLY - 10

ANNUAL COST - $17,500.00

FUEL

 TRACTOR GALLONS CONSUMPTION AMOUNT - 23,529.4 Gallons

COST PER ITEM - $3.90 Per Gallon

MILEAGE PER GALLON (Rating) - 4 mpg

MILEAGE DRIVEN (Miles) - 100,000

REQUIRED ANNUALLY - 95

ANNUAL COST - $91,764.71

ADVANCEMENT FOR SERVICE & FUEL

Total Cost Annually: _$109,264.71_

Total Daily Cost $443.59

TOTAL MILEAGE DRIVEN (Miles) - 100,000

COST PER MILE (Service) - $0.18

COST PER MILE (Fuel) - $0.92

TOTAL COST PER MILE - $1.10

TOTAL WORKING DAYS (Days) - 252

PETERBILT 589 TRI AXLE PAID ADVANCEMENT FOR INSURANCE

Total Cost Annually: _$45,000.00__

Total Daily Cost $178.57

Per Mile Rate: $0.45 Per Mile

INSURANCE

COMMODITY COVERAGE INSURANCE - $500,000.00

LIABILITY COVERAGE - $7,000,000.00

PREMIUM (Tractor) - $40,000.00

PREMIUM (Trailer) - $5,000.00

ANNUAL COST - $45,000.00

REQUIRED PAYMENTS ANNUALLY - 4

PAYMENT PRICE - $11,250.00

TOTAL MILEAGE DRIVEN (Miles) - 100,000

COST PER MILE (Insurance) - $0.45

TOTAL WORKING DAYS (Days) - 252

TOTAL DAILY COST - $178.57

PETERBILT 589 TRI AXLE PAID ADVANCEMENT FOR MISC. EXPENSES

Total Cost Annually: _$143,046.70_

Total Daily Cost $567.65

Per Mile Rate: $1.43 Per Mile

VERIZON CONNECT (Equipment GPS, ELD, Communication)

# OF SERVICES TYPE - (2) Logistics Tracking / DOT Compliance ([2] Tractor / [7] Trailers)

ANNUAL COST - $4,200.00

TRUCKING OFFICE (Trucking Management)

# OF SERVICES TYPE - (2) FMCSA Compliant / Business Tax ([2] Users)

ANNUAL COST - $2,520.00

VERIZON WIRELESS (Samsung Z Fold 6, iPad, Laptop)

# OF SERVICES TYPE - (3) Kenworth Desktop / Virtual Meetings / Communication ([5] Lines)

ANNUAL COST - $3,000.00

LOAD BOARDS (DAT, 123 Load Board, Truckers App)

# OF SERVICES TYPE - (3) Logistics Shipping Lines / Home Loads / Shipping Rates

ANNUAL COST - $4,800.00

HEAVY DUTY RECOVERY (Swing Trailer, Assist Over Railroad Crossing, Stacking, Assisting)

# OF SERVICES TYPE - (3) Extendable Trailers / Doubles & Triples Assembly / Recovery

ANNUAL COST - $85,714.20

EQUIPMENT PARKING (Garage, Shop, Office Utilities, Reserve & Paid Parking)

# OF SERVICES TYPE - 1549 Vance Street / Rocky Mount, NC 27801 (Shared Space w/N.J.R. Logistics Group (25% of 69,500 Sq. Ft. Warehouse & 12 Acres Operating Cost)

ANNUAL COST - $42,812.50

TOTAL OF 14 - Categories FOR A GRAND TOTAL OF $143,046.70

TOTAL MILEAGE DRIVEN (Miles) -100,000

COST PER MILE - $1.43

TOTAL WORKING DAYS - 252

TOTAL COST DAILY - $567.65

2024 XL SPECIALIZED XL 110 MINI-DECK EXTENDABLE TRIDEM AXLE TRAILER

The XL 110 HDE Extend-A-Trac Mini-Deck is the first of its kind in the U.S. market. The main deck features a loaded deck height of only 14 inches, achieved with a 10-inch beam design. Additionally, the trailer’s main deck expands from 27 feet to 47 feet with a total trailer length of 73 feet. The trailer has a capacity rating of 110,000 pounds.

1. Height (up to): ____150”______
2. Width (up to):_____12’_____
   1. No Restrictions: ___Just Weight Allowed _____
   2. Restrictions: ___No Restrictions____
3. Length (up to):__27’_____
   1. No Restrictions: ___If overweight only_____
   2. Restrictions: ___If Trailer Doesn’t Extends, there will not be a permit for length greater than 27’_____
4. Axles: __7 Axles____
   1. Tractor Axles: ____4 Axles____
   2. Trailer Axles: ___3 Axles_____
5. Weight:__100,000 lbs. GCVW________
   1. Legal: ___Max. Weight _______
   2. Permit:__14,285 lbs. Per Axle _____
      1. Permit Weight:__100,000  lbs.____
6. Conglomeration With Other Trailers
   1. 1st Choice Preferred: ___Specializedl___
   2. 2nd Choice Preferred: __Heavy Haul____
   3. 3rd Choice Preferred: ____Open Vehicle Transporter_____
7. Load Board Percentage of Jobs or Freight
8. Percentage of All Shipping Goods Spot Market: ____20%_______

Tridem Axle Extendable Mini Deck

1. Tri Axle Lowboy Trailer
2. Kingpin Spacing - 16”
3. Gooseneck Length: __11’___
4. Belly Length: __27’ to 47’___
5. Rear Deck Length: __15’___
6. Tractor Last Drive Axle Hub to Center of Trailer Axle Illustration - 30.25’
7. Between Which Axles - Center of 2nd Axle
8. Trailer Axle Spacing - 5’ Spacing

First Axle Hub From Nose of Gooseneck - 38.25’

1. First Axle Spacing from Kingpin - 36.92’
2. First Axle Hub From Rear of Trailer - 12.75’
3. Total Spacing - 87.92

Second Axle Hub From Nose of Trailer - 43.25’

1. Second Axle Hub From Kingpin - 41.92’’
2. Second Axle Hub From Rear of Trailer - 7.75’
3. Total Spacing - 92.92’

Third Axle Hub From Front of Trailer - 48.25’’

1. Third Axle Hub From Kingpin - 46.92’
2. Third Axle Hub From Rear of Trailer - 2.75’
3. Total Spacing - 97.92’

LOADING TRAILER

Tridem Axle Trailer

1. Center Lifting Point For Crane (Balance Weight) - 36’ from Front
2. The Most Weight of the shipment Starts at - 2’ From Rear of Well and load towards The Front
3. Last Drive Tire Rear Placement Under Trailer When Coupled - 8’
4. Last Drive Hub to First Trailer Hub Spacing - 32.25’

Any 2 Axles Federal Bridge Weight w/10' or More Spacing Limitations (32’) - 40,000 lbs.

1. First Trailer Axle to Second Trailer Axle Weight Rating (8’) - 34,000 lbs.
2. Second Trailer Axle to Third Axle Weight Rating - 34,000 lbs.

Total Gross Weight Rating

1. Tractor - 62,500 lbs.
2. Trailer - 108,000 lbs.
3. Gross Combination Rating - 170,500 lbs.
4. Number of Axles - 7 Axles

Weight Per Axle - 24,357.1 lbs.

1. No Permit Allowed for -  24,357.1 lbs. Per Axle
2. Permit Approved For Weight - 140,000 lbs. - 20,000 lbs. Per Axle

Eastern Time Zone States with Lowest Rating Per Axle - West Virginia

1. Tandem Axle Weight Allowed w/Permits - 45,000 lbs.
2. Tridem Axle Weight Allowed w/Permits - 50,000 lbs.

West Virginia Oversize Permits

1. In Permits

WEST VIRGINIA OVERSIZE PERMITS INFORMATION

1. PERMITS: West Virginia oversize permits valid for five calendar days. Must have a permit prior to entering the state.

LEGAL DIMENSIONS

Weight: 80,000 Gross on designated routes, 65,000 on non-designated routes)

1. Single – 20,000
2. Tandem– 34,000
3. Tridem – 42,500 (8′ spacings)

ROUTINE PERMIT LIMITS

Weight: 120,000 Gross

1. Single – 28,000
2. Tandem – 45,000
3. Tridem – 50,000
4. “superload” permit can go higher and is usually routine issue

Permit Ordering Max. Weight - 140,000 lbs.

1. Steer - 20,000 lbs.
2. Lift Axle - 20,000 lbs.
3. First Drive Axle - 20,000 lbs.
4. Second Drive Axle - 20,000 lbs.
5. First Trailer Axle - 20,000 lbs.
6. Second Trailer Axle - 20,000 lbs.
7. Third Trailer Axle - 20,000 lbs.
8. Permit Per Axle Weight - 20,000 lbs.
   1. Trailer Tare Weight - 20000 lbs.
   2. Tractor Weight - 30,000 lbs.
   3. Gross Combined Units Tare Weight - 50,000 lbs.

Total Length of Combined Unit - 75’

1. Tare Weight Per Foot - 666.6 lbs.
2. Square Foot of Space Total Combined Unit - 637.5 Sq. Feet
3. Max. Weight of Shipment Allowed - 90,000  lbs.
4. Total Loaded Permit Weight Per Foot - 1,866.6 lbs.

USDOT Weight Per Foot (65’.) - 1,230.7 lbs. Per Ft.

Permit Weight for 27-Tons Bridge Crossing - 89,841 lbs.

USDOT Weight Per Axle for 27-ton Bridge Crossing - 12,834 lbs.

HEAVY WEIGHT

Legal Cargo Dimensions

1. Length - 27 up to 42’
2. Width - up to 12’ Then Structural Engineer has to have a Rectilinear Way of Travel
   1. Uniformity Width For Overwidth Loads in United States
      1. Narrowness Lanes - 8.5’
      2. Broadest Lanes - 12’
      3. Midpoints Lanes - 10.4’
      4. Car Widths - 5.8’
      5. Pickups Trucks Widths - 6.7’
      6. Cargo Vans Widths - 6.6’
      7. Buses & Trucks Mirror Widths - 9’
      8. Midpoints of Motor Vehicles - 7’
      9. Midpoints of Two Motor Vehicles Approaching Each Other
      10. Distance Apart Seperating a Lane - 1.5’
      11. Two Vehicles w/Separating Lane - 15.5’
      12. Midpoints of 2 Lanes w/Separating Lane - 22.3’
      13. Leeway for Oversized Loads - 6.8’
      14. Overhang Load Capacity - 3.5’ One Side
      15. Shipment Redoubtable Width Point - 12’
   2. Fire Hydrants - 5.5’ Back of Curb (No Sidewalk Exist)
   3. Fire Hydrants - 3.5’ Back of Curb (Commercial District)
   4. Trees - 6’ Behind Curb Line (Urban Districts)
   5. Trees - 4’ Behind Paved Roadway (Commercial Districts)
   6. Utilities Poles - 6’ Behind Curb (Urban Districts)
   7. Utilities Poles - 4’ Behind Paved Roadway (Commercial Districts)
   8. Building or Homes - 50’ Behind Road w/No Posted Speed Limit
   9. Building or Homes - 20’ Off Roadway
   10. Subdivision Roads Width - 45’
   11. Collector Roads - 50’
   12. Five Lane Highways -80’
   13. Cul-De-Sacs - 50’
   14. Single Road - 9’ to 15’
   15. Single Lane - 8.5’
   16. “A” Road Lane - 10’ to 12’
   17. Street - 50’
   18. Streets in Old Country Towns - 22’ to 26’
   19. Turn Radius -10’ to 25’

Height - 13’

Power Lines - 18’ Over Highway & Interstates

Power Lines - 14.5’ Residential

Secondary Wires - 16’ Over Highway & Interstates

Communication Wires - 15’ Over Highways & Interstates

Traffic Lights - 15’ Ground Clearance

Traffic Signals and Signs - 14’ and up

Tree Limbs - 14.5’ and up

Pole Lights - 15’ and up

Tunnels  clearance - 14’

Clearance Under Shipment - 4” Underbody of Trailer Height

Telephone Pedestal Box - 36” to 48”

Outdoors Power Pedestal 2 Gang - 30”

Fire Hydrant - 3’ + 6” Landscaping Height = 42”

Guardrail - 29”

COMMODITY TYPE

Type of Commodity

1. Lumber Products
   1. Outdoor Sheds
   2. Modular Homes
   3. Roof Truss

1. Metal Products
   1. Tanks
   2. Frames
   3. Coil
   4. Plants

1. Aluminum Products
   1. Tanks
   2. Ingots
   3. HVAC Units

EQUIPMENT TYPE OF COMMODITIES

1. Shop Machinery
2. Warehouse Machinery
3. Seaport Machinery
4. Railyard Machinery
5. Construction Machinery
6. Oil Field Machinery
7. Motorcoach Equipment

SPECIALIZED TYPE OF COMMODITIES

1. Wind Farm Specialized
2. Warehouse Specialized
3. Manufacturing Specialized
4. Distribution Specialized
5. Refinery Specialized
6. NASA Specialized
7. Government Specialized
8. Airport Specialized
9. Rail Road Specialized
10. Seaport Specialized
11. Construction Specialized
12. Oil Fields Specialized

CUBIC FEET OF SHIPPING TRAILER SPACE

1. # of Section: ___4____

First Section (Required - Yes or No): __Yes (Open)______

1. Length: __47’____
2. Width: ___12’___
3. Height: _13’_____
4. Cubic Feet of Space:__7,332 Cubic Feet_____
5. Empty Weight: ___20,000 lbs._________
6. Max. Weight Legal: ___18,000 lbs. Shipment_____
7. Max. Weight Permit: _51,300 lbs. Shipment______
8. Purpose: ____Multi Purpose____________

Second Section (Required - Yes or No): ___Yes (Open - Rear Deck)_____

1. Length: __15’____
2. Width: ___8.5’____
3. Height: _10.1’_____
4. Cubic Feet of Space:_1,287.75 Cubic Feet______
5. Empty Weight: _8,490.6 lbs.___________
6. Max. Weight Legal: _7,509.4 lbs._______
7. Max. Weight Permit: _20,009.4 lbs.______
8. Purpose: ____Multi Purpose____________

Third Section (Required - Yes or No): __Yes (Closed)______

1. Length: _27’_____
2. Width: ___12’____
3. Height: __13’____
4. Cubic Feet of Space:_4,212 Cubic Feet______
5. Empty Weight: ___18.000 lbs._________
6. Max. Weight Legal: _28,800 lbs._______
7. Max. Weight Permit: __50,000 lbs._____
8. Purpose: ____Multi Purpose____________

Fourth Section (Required - Yes or No): __Yes (Closed)______

1. Length: __15’____
2. Width: ___8.5’____
3. Height: _10.1’_____
4. Cubic Feet of Space:_1,287.75 Cubic Feet______
5. Empty Weight: _8,490.6 lbs.___________
6. Max. Weight Legal: _7,509.4 lbs._______
7. Max. Weight Permit: _20,009.4 lbs.______
8. Purpose: ____Multi Purpose____________

PETERBILT 589 TRI AXLE PAID ADVANCEMENT FOR OVER THE ROAD EXPENSES

Total Cost Annually: _$40,152.00

Total Daily Cost $159.53

Per Mile Rate: $0.40 Per Mile

FOOD (Meals, Snacks, Drinks)

TYPE OF SERVICE - $10.00 Per Day For Meals and Drinks

ANNUAL COST - $3,650.00

SHOWERS (Soap, Lotion, Razors, Shaving Cream, Alcohol, Toothpaste, Vaseline)

TYPE OF SERVICE - $2.00 Per Day for Showers

ANNUAL COST - $502.00

LOGGING (When Renting a Vehicle Waiting for a Load to Generate)

TYPE OF SERVICE - $200.00 Per Monthly

ANNUAL COST - $2,400.00

WASHING & DRYING (Washing 3 Loads Weekly)

TYPE OF SERVICE - $25.00 Weekly for Washing & Drying

ANNUAL COST - $1,300.00

TRUCK & TRAILER DETAILING (Washing Equipment and Polishing)

TYPE OF SERVICE - $400.00 Weekly for Washing, Detailing Interior, Polishing Chrome

ANNUAL COST - $20,800.00

TOLLS, SCALES & TIPPING (PrePass, Tipping Restaurants, Mechanics, Warehouse & Detailing)

TYPE OF SERVICE - Tolls ($10.00 per 100 miles / Tipping 15%

ANNUAL COST - $11,500.00

TOTAL OF 8 - Categories FOR A GRAND TOTAL OF $40,152.00

TOTAL MILEAGE DRIVEN (Miles) - 100,000

COST PER MILE - $0.52

TOTAL WORKING DAYS - 252

TOTAL COST DAILY - $208.25

PETERBILT 589 TRI AXLE PAID ADVANCEMENT FOR SELF PAY EXPENSES

Total Cost Annually: _$100,000.00

Total Daily Cost $396.83

Per Mile Rate: $1.00 Per Mile

HOUSING (Insurance, Taxes, Utilities & Savings)

SERVICE TYPE - 4,500 to 5,500 Square Feet Home on 2 Acres or More Residential Property

ANNUAL COST - $21,000.00

BUSINESS VEHICLES (Heavy Duty Diesel Pickup / Full Size Diesel SUV / Full Size Electric SUV)

SERVICE TYPE - Off Road Use, Towing, Meeting Transportation Vehicle and Supplies Runner

ANNUAL COST - $10,500.00

MOTORHOME & STACKER TRAILER (Prevost Featherlite Coach)

SERVICE TYPE - Touring Vehicle with 2 Car Garage

ANNUAL COST - $10,500.00

PERSONAL VEHICLE (Sports Car, Luxury Vehicle)

SERVICE TYPE - Manual Sportscar and a Luxury Vehicle

ANNUAL COST - $10,500.00

ENTERTAINMENT (Fishing, Flying, Racing, Video Games, Card Games, Heavy Equipment)

SERVICE TYPE - Fishing in Chesapeake Bay, Operating Heavy Equipment, Erecting Lumber and Steel, Racing on Road Course, Movies, Bowling, Simulator Games)

ANNUAL COST - $47,500.00

TOTAL OF 5 - Categories FOR A GRAND TOTAL OF $100,000.00

TOTAL MILEAGE DRIVEN (Miles) - 100,000

COST PER MILE - $1.00

TOTAL WORKING DAYS - 252

TOTAL COST DAILY - $396.83

Lowe's

Store# 0547

700 N. Wesleyan Blvd,

Rocky Mount, NC 27804

Store Phone# (252)451-1161

NOTES:

The entire Shipment is to be delivered to ARI for Installation into Kenworth W990 Tri Axle Purchase from MHC Kenworth in Battleboro, NC. The Grill is to be removed from Base to be installed in Back of Sleeper with remote Slide out behind Sleeper and in front of Headache Rack and a 55" Google TV on a Slide Out as well. Two Twin Recliners in Sleeper with Electric Upper Bed

Lowe's PRO Quote Name: ARI SLEEPERS CONTRACT

Quote# 226222436

Created on: September 12, 2025

Quote Valid Until: October 13, 2025 at 11:59pm

Created By: Tariq Robinson

E-Mail: tariq.robinson1969@gmail.com

Phone #: (252)903-3751

Pro Rewards Contractor: Naomi Jeanette Robinson Trucking

Pro Rewards Contractor Phone# (252)877-2108

PO# ARI Legacy II Custom Sleeper

DELIVERY ADDRESS:

ARI Legacy Sleepers

860 N. Tuscany Drive

Shipshewana, IN 46565

(260)768-4704

ORDER SUMMARY

#of Items: 11

Savings: $0.00 (17.7%)

Delivery Fees & Taxes: Calculated in Checkout

Estimated Total - $0.00

Estimated Points - 0.0 points

Samsung Family Hub 21.5 Cubic Feet Counter-Depth Side by Side Refrigerator Smart Compatible w/Ice Maker

1. Width - 35.875"
2. Depth - 28.6"
3. Depth w/Door Open - 46.4"
4. Height to Top of Door Hinge - 70.1"
5. Weight - 356 lbs.
6. ITEM# 1689418
7. PRICE - $2,199.00

Samsung Bespoke Stormwash+ w/3rd Rack Wash System 24" Top Control Built in Dishwasher

1. Depth - 25"
2. Depth w/Door Open - 49.62"
3. Width - 23.87"
4. Height - 35"
5. Weight -88.2 lbs.
6. ITEM# 6766420
7. PRICE - $999.00

Bosch Programmable Residential Combination Coffee Maker w/Automatic Shut off

1. Depth - 21"
2. Height - 17.875"
3. Weight - 70 lbs.
4. Width - 23.375"
5. ITEM# 805510
6. PRICE - $3,999.00

Samsung Bespoke AI Laundry Hub Stacked Laundry Center w/4.6 Cubic Feet Front Loader Washer and Electric Dryer

1. Depth w/Door Closed - 31.3"
2. Depth w/Door Open - 53.1"
3. Height - 74.4"
4. Weight - 319.7 lbs.
5. ITEM# 5682937
6. PRICE - $1,998.00

Dreamline Flex 2-Piece 36"W x 36"L x 75"H Square Corner Shower Kit (Corner Drain)

1. Height - 74.75"
2. Length - 36"
3. Width - 36"
4. Actual Door Opening Height - 72"
5. Actual Door Opening Width - 22.875"
6. Actual Shower Floor Height - 2.75"
7. Weight - 163.58 lbs.
8. ITEM# 836086
9. PRICE - $1,319.99

Oaks Decor Cotti 20" Integrated LED Flush Mount Smart Matte Black w/Clear Blades Fandelier Ceiling Fan w/Light

1. Width - 20"
2. Fan Diameter - 20"
3. Weight - 7.5 lbs.
4. Width - 20"
5. Hanging Height - 5".
6. ITEM# 4839290
7. PRICE - $79.98

Charbroil Commercial Series Grill and Griddle Combo Stainless Steel 4-Burner Infrared Liquid Propane & Natural Gas

1. Depth - 22.5"
2. Height - 47.2"
3. Weight - 155 lbs.
4. Width - 58.8"
5. ITEM# 5506271
6. PRICE - $699.00

Kohler Smart Toilets White Elongated Standard Height 12" Rough-in Watersense 1.28 GPF Dual Flush w/Sensor Smart Compatible Soft Close 1-Piece Toilet

1. Depth - 28.325"
2. Height - 25"
3. Weight - 117.18 lbs.
4. Width - 17"
5. Bowl Height w/Seat - 18"
6. Power Cord Length - 4.67'
7. ITEM# 5508605
8. PRICE - $2,550.00

Kohler Prolific Undermount 44" x 18.25" Stainless Steel Single Bowl 18-Gauge Workstation Kitchen Sink

1. Cutout Length - 42.5"
2. Cutout Width -14,94"
3. Depth of Bowl -10.13"
4. Drain Connection Diameter - 1.5"
5. Length - 44"
6. Min. Cabinet Size - 36"
7. Weight - 32.63 lbs.
8. Width - 18.25'
9. ITEM# 6290624
10. PRICE - $2,283.11

Empava Electric Stove w/Dual Elements 12" (2) Burners Smooth Surface (Radiant) Black Electric Cooktop

1. Depth - 20.47"
2. Width - 11.33"
3. Height -?
4. Cutout Depth - 19.69"
5. Cutout Height - 5"
6. Cutout Width - 10.63"
7. Weight - 0.0 lbs.
8. ITEM# 4797642
9. PRICE - $195.36

Kitchenaid 1.1 Cubic Feet Air Fry Over The Range Convection Microwave w/Sensor Cooking (Juniper)

1. Cutout Depth - 13"
2. Cutout Height - 18"
3. Cutout Width -30"
4. Depth - 12.75"
5. Depth w/Door Open - 41.5"
6. Height - 17.87
7. Weight - 75 lbs.
8. Width - 30"
9. ITEM# 7370697
10. PRICE - $1,498.46

Good afternoon, Tariq.

Here are some drawings for you to look over.  I did an interior drawing, top view, and the truck frame specks.  This is only the first draft of your sleeper.  I believe I have everything we discussed in the design.  Please look these over and let me know if you have any questions or would like to make any changes.   As the design and options are up to you, we can make any changes we need to have your sleeper the way you want and need it.

Thank you

Tommy Milham

Alliance Truck Group LLC

Sales Manager

260-463-3244 x 108

Our state-of-the-art tractor is equipped with the latest tools and equipment to handle any Heavy Haul or Specialized Loads.

• Total Frame Length ..........477" (39.75')
• Wheelbase .......... 386" (32.16')

FRONT TO REAR [Inches (Feet)]

• Steer Axle Hub ..........31" (2.58)
• Steer Axle Hub to End of Cab ..........100" (8.33')
• End of Cab to Lift Axle ...........205" (17.08')
• Lift Axle to Drive Front Hub .......... 54" (4.5')
• Drive Hub Front to Wheelbase .......... 27" (2.25')
• Wheelbase to Rear Drive Hub ..........27" (2.25')
• Rear Drive Hub to End of Frame .......... 33" (2.75')

REAR TO FRONT [inches (Feet)]

• End of Frame to Beginning of 72" Sliding 5th Wheel Frame (Locking Jaw): .......... 30" (2.5')
• Beginning of 72" Sliding 5th Wheel Frame to End of 72" Sliding 5th Wheel Frame .........72" (6')
• End of 72" Sliding 5th Wheel Frame to Front Headache Rack (Vader Black Angled Face Aluminum Headache Rack - 80"W x 70"H x 14"D - 365 lbs. Tare Weight) ..........48" (4')
• Beginning of Headache Rack to Back of Sleeper ..........17" (1.41')
• Back of Sleeper to Rear of Day Cab (Peterbilt 589 Ultra Cab) ..........144" (12')
• Back of Day Cab to Front Bumper (Texas Square Bumper / Not Tow Hook in Front) ..........131" (10.91')

FUEL TANKS LOCATION

• Right Side (Front Bumper to End of Frame Spacing (Inches) ..........224.5" (18.70')
• Left Side (End of Frame to Front Bumper Spacing (Inches) ..........118" (9.83')

44" TOOL BOX REPLACE WITH PROPANE GRILL & GRIDDLE COMBO (Slide out behind Fuel Skirt on Passenger Side)

• Front Bumper to Grill Slide Out (Inches): ..........137" (11.41')

WALK IN STEPS LOCATION ON PASSENGER SIDE

• Front Bumper to Door Opening .......... 184" (15.33')

TRACTOR TURNING DIAMETER FOR URBAN CITIES (Steer Axle set at 50° Angle)

• Right Turn 90° ..........69.56' Space (5.79 Lanes = Requires a Two Lane Highway without a median to make a Right Turn without backing
• Left Turn 180° ..........139.12' Space (11.17 Lanes = Requires a 100' Median to make a U-Turn without backing

FEDERAL BRIDGE RATING REQUIREMENT

• Tare Weight - 30,000 lbs. or Under
• Spacing Requirement for 30,000 lbs. on a Bridge Deck ..........25.18' Deck Spacing
• Bridge Crossing Requirement .......... 30 Tons or More

Lowe's PRO Quote Name: ARI SLEEPERS CONTRACT

Quote# 226222436

Created on: September 12, 2025

Quote Valid Until: October 13, 2025 at 11:59pm

Created By:

1. Tariq Robinson - Pro Sales Specialist
2. Naomi Jeanette Robinson Logistics Group (Welding & Fabrication Department)

E-Mail: tariq.robinson1969@gmail.com

Phone #: (252)903-3751

Created For: Naomi Jeanette Robinson Trucking LLC

Lowe's Pro & Commercial Account

DRIVER SIDE (Left Side) DIMENSIONS

• Length
• Width
• Height
• Appliances Requested in This Location

CENTER AISLE (Walkway) DIMENSIONS

• Length
• Width
• Height
• Appliances Requested in This Location

PASSENGER SIDE (Right Side) DIMENSIONS

• Length
• Width
• Height
• Appliances Requested in This Location

INTERIOR REAR DIMENSIONS

• Length
• Width
• Height
• Appliances Requested in This Location

FUEL SKIRT LEFT SIDE DIMENSIONS

FUEL SKIRT RIGHT SIDE DIMENSIONS

ROOFTOP DIMENSION

Tommy Milham

Alliance Truck Group LLC

Sales Manager

260-463-3244 x 108

Good afternoon, Tommy

I need this custom sleeper built for park for several days without bare essential at a location where DOT Authorized parking Permit is isolated without retail and food stores in a remote location. Bigger Water Tanks, Grill Combo Behind the fuel skirt remote Slide out if possible. An Awing with Bug Screen Protection while grilling outdoors. A Small Refrigerator behind fuel skirt.

I also need radiant heating floors in the sleeper as well. If we can Slide a TV under the Fuel Skirt Lets do that as well. I have a Pro Quote with Lowe's of Rocky Mount, NC for 13 Items to be installed in the sleeper.  I have more items than space. So I want the grill under the sleeper behind fuel skirts. I have Concrete boards to go under the radiant Heat Floor Kit.

I will like the Stack Washer and Dryer in the sleeper. I don't want old clothes smell in my sleeper without washing resources available. I also Like the Bosch Refrigerator inside the sleeper as well. It allows me to have a Month or better supply of food.

I like the stand up Shower in the sleeper seperate from the toilet. If we can do an Electric Bed with 2 Recliners underneath. That will be awesome.

The Bed I am thinking about Farmers Queen Bed with Pop Up Remote Control TV with Fire Place . That will Increase my space in the sleeper for my Computer Station. However I want the Recliners as well. Let me get the priorities first inside and we will work on the rest.

Thank you

Tariq Robinson - Lowe's Pro Sales Specialist (Rocky Mount, NC)

N.J.R. Trucking

144" Sleeper Shell Specs

• Total Shell Length (Right & Left Combined) ..........288" (24')
• Total Lowe's Pro Appliance & Kitchen and Bath Items for Installation) ..........13
• Average Width Per Item Installed..........22.15" per item (No Cabinets  or Closet Included in Avg.)

Peterbilt 589 or Kenworth W990 Powertrain, Rims & Tires Requested

• Alcoa Bright Aluminum Rims Size Requested .......... 24.5 Rims
• Tires Manufacturer Requested: .........Michelin Low Profile (1st Choice)
• Engine Manufacturer Requested: .......... Caterpillar (1st Choice)
• Engine Horsepower Requested: .......... 600 hp
• Transmission Manufacturer Requested: .......... Eaton Fuller
• Transmission Type: ..........Manual  - Super 18 Speed
• Aux. Transmission Type: ..........2 Speed

Steer Tires Diameter Requested

• Inside Diameter  ......... 24.5"
• Outside Diameter .........37.5"
• Width ..........16"
• Rating ..........9,600 lbs.
• # of Tires .......... 2
• Total Axle Tires Rating: ..........19,200 lbs.

Lift Axle Tire Diameter Requested

• Inside Diameter ……….24.5”
• Outside Diameter ……….37.5”
• Width .......... 19"
• Rating ..........11,400 lbs.
• # of Tires .......... 2
• Total Axle Tires Rating ..........22,800 lbs.

Drive Axle Tire Diameter Requested

• Inside Diameter  ......... 24.5"
• Outside Diameter .........37.5"
• Width ..........10"
• Rating ..........6,000 lbs.
• # of Tires .......... 8
• Total Axle Tires Rating ..........48,000 lbs.

Peterbilt 589 or Kenworth W990 Frame & 5th Wheel Specs.

Frame Dimension Requested

• Frame Type: .........Double
• Frame Depth: ..........14"
• Frame Height: ..........40"
• Frame Length: .......... 477"
• Ride Height: ..........18.75"

5th Wheel Requirements Requested

• Manufacturer Requested (1st Choice): .........Fontaine Specialized
• Sliding Length: ..........72"
• 5th Wheel Frame Height: ..........10"
• 5th Wheel Coupling Plate Height ..........50"
• 5th Wheel Plate Rating ..........25 Tons (Locking Jaw Plate)

Peterbilt 589 or Kenworth W990 Lower 48 States Requirement Requested

• Steer Axle Requested: ..........18,000 lbs.
• Lift Axle Requested: .........20,000 lbs. Steerable
• Tandem Drive Axle Requested: .........46,000 lbs.
• Frame Weight (Powertrain, Cab and VIP Interior w/Black Leather Interior, Gauge Packages) Weight ..........23,750 lbs.
• Lowe's Pro Account Items Weight ..........1,416 lbs.
• 144" Shell, Cabinets, Tanks, Generator, Batteries, Wires and Pipes Tare Weight - .......... 1,500 lbs.
• Total Weight Anticipated ..........26,666 lbs.

Interior of 144" Sleeper Shell Specs

• Shell Width ..........96"
• Shell Length ..........143.5"
• Shell Height .........96"

Custom Interior Requested Dimension:

• Right Side Cabinets ..........32"
• Center Aisle ..........30"
• Left Side Cabinets ..........34"
